TOUCHSCREENVIDEODOORPHONE
USER MANUAL
Thank you for purchasing our products.
The products are subject to change without prior notice.
The company is not responsible for any safety accidents caused by abnormal
operation of the product.
Please carefully read this User's Guide(in particular, precautions for safety)
before using a product and follow instructions to use a product exactly.
V1.1
Advertisement
Table of Contents
Related Manuals for Altronics S9395
Summary of Contents for Altronics S9395
- Page 1 TOUCHSCREENVIDEODOORPHONE USER MANUAL Thank you for purchasing our products. The products are subject to change without prior notice. The company is not responsible for any safety accidents caused by abnormal operation of the product. Please carefully read this User’s Guide(in particular, precautions for safety) before using a product and follow instructions to use a product exactly.
-
Page 2: Table Of Contents
Index Warning and caution ---------------------------------------------------------------------1,2 The function and name of each part ---------------------------------------------------3 Features and main function ---------------------------------------------------------------4 Package contents ---------------------------------------------------------------------------4 Wiring diagram ----------------------------------------------------------------------------5,6 System layout --------------------------------------------------------------------------------7 Installation method --------------------------------------------------------------------------8 Specification ---------------------------------------------------------------------------------8 Cable specification --------------------------------------------------------------------------9 Shortcut menu ------------------------------------------------------------------------------10 Incoming call answer / Call transfer -------------------------------------------------- 11 Internal call among monitors ------------------------------------------------------------11 Talking color/brightness/contrast/volume/zoom adjust ---------------------------11 Manual record an audio ------------------------------------------------------------------12... -
Page 3: Warning And Caution
Warning and caution Make sure to follow the instructions to prevent any danger or property losses. It indicates prohibition of contact. It indicates prohibition disassembly. It indicates prohibition of contact. Warning It indicates dangerous. Death or serious It indicates that the plug should be pulled out injury is expected. - Page 4 It indicates prohibition of contact. It indicates prohibition disassembly. It indicates prohibition of contact. CAUTION It indicates dangerous. A injury or property It indicates that the plug should be pulled out losses are expected. from the socket. The socket holes are lager than usual.
-
Page 5: The Function And Name Of Each Part
The function and name of each part Power indicator light Microphone Return / hang off / Enter main menu Power on / off Micro SD card slot Remak: 1.Gate unlock should connect unlock driver aid. 2.Make sure micro SD card is class 10, FAT32. Page3... -
Page 6: Features And Main Function
Features and main function 1. Features 7" Color capacitive touch screen Hands free design, perfect intercom with clear voice The optional multi-language friendly interface 13 polyphonic ring-tones switch freely Easy to operation Compatible with most models of CVBS / AHD / CVI / TVI (Optional) 2. -
Page 7: Wiring Diagram
Wiring diagram Solution1 AD-OUT DATA VD-OUT ROOM4 AD-IN CCTV1 CCTV1 DATA CCTV2 CCTV2 VD-IN PWR2 PWR1 KEY2 KEY1 AD-OUT DATA VD-OUT ROOM3 AD-IN CCTV1 CCTV1 DATA CCTV2 CCTV2 VD-IN PWR2 PWR1 KEY2 KEY1 AD-OUT DATA VD-OUT ROOM2 AD-IN CCTV1 CCTV1 DATA CCTV2 CCTV2... -
Page 8: Wiring Diagram
Wiring diagram Solution2 AD-OUT DATA VD-OUT ROOM4 AD-IN CCTV1 CCTV1 DATA CCTV2 CCTV2 VD-IN PWR2 PWR1 KEY2 KEY1 AD-OUT DATA VD-OUT ROOM3 AD-IN CCTV1 CCTV1 DATA CCTV2 CCTV2 VD-IN PWR2 PWR1 KEY2 KEY1 AD-OUT DATA VD-OUT ROOM2 AD-IN CCTV1 CCTV1 DATA CCTV2 CCTV2... -
Page 9: System Layout
System layout 1. The port 2 connect doorbell panel The system can maximum support 1 main monitor, 3 sub monitors, 2 door panels and 8 CCTV cameras. Master Sub Monitor Sub Monitor Sub Monitor Door 1 CCTV1 CCTV1 CCTV1 CCTV1 Door 2 CCTV2 CCTV2... -
Page 10: Installation Method
Installation method 1. Refer to relevant wiring diagram for the system you have chosen and ensure you have the correct cable. 2. Determine the monitor installation position: suggest to install at 1.5~1.6Meters. 3. Ensure no power supply connection before installation finished. 4. -
Page 11: Cable Specification
Cable specification The System has 2 solutions to unlock the door: Unlock signal from doorbell or unlock signal from monitor. When unlock signal is from doorbell: a. please choose coaxial cable SYV-75-5 for video, with another RVV4x0.5mm (within 30 meters); b. -
Page 12: Shortcut Menu
Shortcut menu At standby state, press to enter main menu as below Figure. 16:06 December 18,2018 Functions Notes Make intercom call to other monitors & Talk with the visitor Record family audio message Monitor listening to other indoor monitors Watch outdoor station or CCTV Make broadcast to others Setting menu Select the target file and click... -
Page 13: Incoming Call Answer / Call Transfer
Incoming call answer / Call transfer When a visitor calls in doorbell, all the indoor monitors in this house will chime simultaneously as below: INCOMING CALL Picture1 Picture2 The LCD will show “INCOMING CALL”. Click to talk with the visitor, as picture1. Click to transfer the call to other monitors. -
Page 14: Manual Record An Audio
Manual record an audio At main menu state, click in menu to record an audio manually, click icon again to end the recording. Monitor listening At main menu state, click icon to start the monitor listening function. If you have more than 2 indoor monitors ,there would be option rooms for choosing on screen, click the target indoor intercom to do monitor listening. -
Page 15: System Setting
c. Capture image automatically: go to the setting and set “01” in “AUTO CAPTURE QUANTITY”, then the system will capture a image & save it automatically when someone press the doorbell. System settings At the standby state, press icon to enter system main menu, click the to the system settings menu as below figure: LANGUAGE ENGLISH... - Page 16 Options Note Setting items Choose the right language as you like. Multi-Language LANGUAGE The indoor monitor will be mute & the power indicate light will flicker once ENABLE someone presses doorbells / make DO NOT internal call / broadcast. DISTURB DISABLE Can be listening monitored by other ENABLE...
-
Page 17: Dvr Function
DVR function At main menu, click icon to setting, click the icon to DVR SETTING. DISABLE FRAME RATE RESOLUTION 1280 720 MOTION DETECT SENSITIVITY DISABLE BEGIN TIME 06 : 00 END TIME 06 : 00 RECORD LOCATION DOOR1 TIME SCREEN SAVER ENABLE MOTION SCREEN SAVER ENABLE... -
Page 18: Alarm Clock Setting
DVR Settings Options Setting items Note ENABLE Activate DVR function DISABLE 5 / 10 /15 / 20 / 25 FRAME RATE FRAME/S 1920x1080 / 1280 RESOLUTION x720 / 640x480 HIGH / NORMAL Detect motions as HIGH / NORMAL MOTION DETECT / LOW / LOW levels SENSITIVITY... -
Page 19: Chime Setting
Options Setting items Note SYSTEM TIME SETTING HOUR / MINUTE / SECOND SYSTEM DATE SETTING DAY / MONTH / YEAR ALARM RING TYPE 01 to 13 DISABLE will alarm 1min at the set time everyday ALWAYS ALARM CLOCK will alarm 1min at the set time on the SUN to SAT right day Remark: click...
