- Page 1 M2M CAPTURE SOFTWARE NSTALLATION GUIDE June 2019 | Ref : CAPTURE_INSTALLATION_GUIDE_how_to_install_CAPTURE_US - B...
- Page 2 SUMMARY INSTALLATION OF… 1. CAPTURE SOFTWARE ON THE DEVICE 2. CAPTURE PC 3. CAPTURE VIEWER...
-
Page 3: Capture Software
CAPTURE SOFTWARE INSTALLATION PROCEDURE (1/6) 1. Download the « Capture_Update_3.X.cap » file on the website. 2. Copy the « Capture_Update_3.X.cap » file on the root of a USB disk. 3. On GEKKO or MANTIS, press to access to the general settings. Current release... - Page 4 Note: This process shall be done with the equipment connected to the AC Power supply.
- Page 5 CAPTURE SOFTWARE INSTALLATION PROCEDURE (2/6) 4. Press on “Upgrade”. Current release...
- Page 6 CAPTURE SOFTWARE INSTALLATION PROCEDURE (3/6) 5. The name of the release 3.X. appears. Press on “Upgrade”. Current release...
- Page 7 CAPTURE SOFTWARE INSTALLATION PROCEDURE (4/6) 5. Repository update. If you press ”Yes”, you will update all the libraries (specimens, probes, and scanner) and the applications. This procedure will not erase the existing user files. Only the files installed within our repository and with the same name will be replaced. If you press “No”...
- Page 8 CAPTURE SOFTWARE INSTALLATION PROCEDURE (5/6) 7. Wait the reboot of your device Current release...
- Page 9 CAPTURE SOFTWARE INSTALLATION PROCEDURE (6/6) 8. The new release is now available In case of problem, please contact the support team support-m2m@eddyfi.com Current new release...
- Page 10 CAPTURE PC INSTALLATION PROCEDURE (1/2) PC CONFIGURATION NEEDS - Operating system: Windows 7 /Windows 8/ Windows 10 - Archive management tool (7z, WinRAR, WinZip...) 1. Download the « Capture_PC_3.x.exe » file and extract the contents (folder location free). Extracting operation generates the « Capture_PC_3.x » folder. 2.
- Page 11 CAPTURE PC For this reason, you need to configure the windows UAC at the minimum level (see next page) INSTALLATION PROCEDURE (2/2) 2. Windows UAC configuration - Go to user account then Modify the user account parameters in the Control panel - Set the scale button to its minimum level as shown on the right picture Once all steps are done, restart your PC...
- Page 12 Admin » after right-click on the Go_Capture file. - The CAPTURE Home page should appear as shown on the right picture • If a crash occurs, please repeat the installation steps and try again. • In case of problems, please contact support-m2m@eddyfi.com...
- Page 13 CAPTURE VIEWER INSTALLATION PROCEDURE (1/2) You don’t need a dongle to launch the Capture Viewer 1. Upload and extraction of the file. • Copy the file “Capture_Viewer_3.X.exe” on your computer. • Double-click on the file. • Select the saving location then extract.
- Page 14 CAPTURE VIEWER INSTALLATION PROCEDURE (2/2) 2. Launch the viewer • To launch the software, open the file “Capture_Viewer_3.X.exe” and double-click on “Go_Capture_Viewer.bat”.
- Page 15 CAPTURE VIEWER LAUNCHING CAPTURE VIEWER 2. Launch the viewer • The CAPTURE viewer Home page is displayed.
- Page 16 CAPTURE VIEWER LOAD YOUR FILE (2/2) 3. Import your file • Click on the import button to import inspection files from the computer or an external drive. • Select the inspection file from the Home panel then press Start to begin the analysis.
- Page 17 CAPTURE VIEWER START THE ANALYSE 4. Open the inspection file and start the analyse • The viewer software offers basic analysis tools. • Please refer to the document GEKKO_New features_US-A and to the GEKKO user manual for further information about the analysis tools.
- Page 18 CAPTURE VIEWER • In case of problem, please contact the support team support-m2m@eddyfi.com...
- Page 19 - m2m@eddyfi.com...
