- Page 1 TECHNICAL DOCUMENTATION | M2M MANTIS Redacted by Ouarda TOUDERT Approved by Fabien DURAND Date : 10/01/2019 Revision B.2 © 2019 Eddyfi Technologies...
-
Page 2: Table Of Contents
SUMMARY MANTIS_MECHANICAL DRAWING MANTIS_PHASED ARRAY CONNECTOR MANTIS_UT CONNECTOR MANTIS_ENCODER CONNECTOR MANTIS_POWER CONNECTOR MANTIS_BATTERY SLOT MANTIS_FRONT PANEL MANTIS_I/O CONNECTORS MANTIS_ACCESSORIES 10. MANTIS_GLOBAL WARNING 11. MANTIS_BATTERY WARNING 12. MANTIS_CLEANING 13. MANTIS TECHNICAL SPECIFICATIONS... -
Page 3: Mantis_Mechanical Drawing
1. MANTIS_MECHANICAL DRAWING... -
Page 4: Mantis_Phased Array Connector
2. MANTIS_ PHASED ARRAY CONNECTOR Connector Location Connector Utility • Connect Phased-array probe equipped with I-PEX connector. • Our system is able to communicate with intelligent probe specially designed for MANTIS. Connector Information Connector Mapping Preview Supplier: I-PEX See next page for detailled view Reference: 30046-160T-F Matching Connector Supplier: I-PEX... - Page 5 2. MANTIS_ PHASED ARRAY CONNECTOR Connector Mapping 1/2 Connector Signal Description Signal Description User matching signal Name Phased-array Phased-array probe channel 1 ER1 to ER64 channel number 1 to to 64 For better ultrasound result, all GND pin have to be connected Ground pin to probe ground.
- Page 6 2. MANTIS_ PHASED ARRAY CONNECTOR Connector Mapping 2/2 Connector Signal Description Signal Description User matching signal Name Phased-array Phased-array probe channel 1 ER1 to ER64 channel number 1 to to 64 For better ultrasound result, all GND pin have to be connected Ground pin to probe ground.
-
Page 7: Mantis_Ut Connector
3. MANTIS_UT CONNECTOR Connector Location Connector Utility • On MANTIS system, There are one UT channel that can be used: • 1- Separated transmitter/receiver mode. • P/R: transmitters • R: Receiver • 2- Connected transmitter/receiver mode. • P/R: transmitters / Receiver •... -
Page 8: Mantis_Encoder Connector
4. MANTIS_ENCODER CONNECTOR Connector Location Connector Utility • CONNECT UP TO 3 DIFFERENT ENCODER: These encodes are +5V TTL inputs. We are able to manage quadrature mode or clk/dir mode. The number of encoder available (2 or 3) depends on the chosen software package. •... - Page 9 4. MANTIS_ ENCODER CONNECTOR Connector Mapping...
- Page 10 4. MANTIS_ ENCODER CONNECTOR Connector Signal Description 1/3 Signal Name Description User matching signal Encoder 1 phase A Encoder 1 phase A Connected to the encoder 1 output A (TTL +5V) Encoder 1 phase B Encoder 1 phase B Connected to the encoder 1 output B (TTL +5V) Encoder 2 phase A Encoder 2 phase A Connected to the encoder 2 output A (TTL +5V)
- Page 11 4. MANTIS_ ENCODER CONNECTOR Connector Signal Description 2/3 Signal Name Description User matching signal If configured as output, MANTIS system generate a 5V/100ns pulse for each physical pulse greated by the system. This signal can be used to synchronize an external system or another MANTIS. The Jitter on this output is 10ns. If configured as input, MANTIS system ultrasound PRF can be managed by an Synchro1 Synchro1 input/output (TTL 5V)
-
Page 12: Mantis_Power Connector
5. MANTIS_POWER CONNECTOR Connector Location Connector Utility • This connector is the global system power supply. • When plugged, the external power supply is used to : • Power the system, • Charge batteries if they are not completely charged. •... - Page 13 5. MANTIS_POWER CONNECTOR Connector Mapping When the power cable is plugged, the position of the system should allow to easily unlock the connector. This in order to cut power in an emergency.
-
Page 14: Mantis_Battery Slot
6. MANTIS_BATTERY SLOT Connector Location Battery Charge-discharge There are two batteries on MANTIS System. Internal battery and External battery: WHEN PLUGGED, THE WALL ADAPTER : • Provide power for batteries charge (system power off) : - If only one battery is plugged, this battery will be charged in 3 hours (if completely low). -
Page 15: Mantis_Front Panel
7. MANTIS_FRONT PANEL Front Panel View Meaning BATTERY STATUS • Push the « BATT » button to check the level of battery : • Charged above 30%, LED is green during 5 second. • Charged between 10 to 30%, LED is orange during 5 second. •... - Page 16 7. MANTIS_FRONT PANEL Front Panel View Meaning CLICKABLE SCROLL WHEEL Use the wheel to change parameter value and to move cursors. • Turn the clickable scroll wheel to move cursors. • Turn the clickable scroll wheel to increase/decrease a specific digit •...
-
Page 17: Mantis_I/O Connectors
8. MANTIS_IO CONNECTOR Connector Location Connector Utility • Two USB port. Each port can accept any USB compatible devices. • USB3.0: super speed USB, can transfers data at up to 625 MB/s. • USB2.0: Standard USB. USB3.0 device can be connected, but with USB2.0 speed. -
Page 18: Mantis_Accessories
9. MANTIS_ACCESSORIES_PROBE Accessory Name Description Picture IPEX FRB Adaptator This adaptator is needed to connect an HYPERTRONICS (FRB) probe to EDDYFI ref: ADAPT_IPEX_FRB_V2 the MANTIS system. SPLITTER 1x64 -> 2x32 The 64 MANTIS channel are splitted to 2 different I-PEX connectors able to EDDYFI ref : SPLITTER-2x32 receive 32 channel probe. - Page 19 9. MANTIS_ACCESSORIES_BATTERIES Accessory Name Description Picture BATTERY Additionnal battery. EDDYFI ref : GEK_BATT BATTERY CHARGER External dual battery charger able to recharge 2 MANTIS batteries in EDDYFI ref : GEK_CHARGER 4hours.
- Page 20 9. MANTIS_ACCESSORIES_CABLES Accessory Name Description Picture Scanning cable adaptor for MicroD25 This cable is needed to connect systems MicroD25 connector equipped EDDYFI ref : CAB_0069 accessories to MANTIS system. Scanning cable adaptor for SUBD15 This cable is needed to connect SUBD15 system connector equipped accessories to EDDYFI ref : CAB_0104...
-
Page 21: Mantis_Global Warning
10. MANTIS_GLOBAL WARNINGS Do not use the device for purposes other than those for which it was designed. Not inspect parts of the human body or animal body with MANTIS systems. The use of non-compatible devices can cause device failure. To avoid personal injury or property damage, do not disassemble, modify or attempt to repair the unit. - Page 22 10. MANTIS_GLOBAL WARNINGS To avoid injury, be careful not to place your fingers between the support leg and body of the system and in any connector of the system. Avoid touching the inner conductor of I-PEX and LEMO connectors to reduce the risk of electric shock. The tension of the inner conductor of UT connectors can reach 315 V and the voltage of the inner conductor PA connector can reach 135 V.
-
Page 23: Mantis_Battery Warning
11. MANTIS_BATTERY WARNINGS Do not attempt to open, crush or puncture the battery; this may cause injury. Do not incinerate. Keep the battery away from fire and other sources of extreme heat. Exposure of battery to extreme heat sources (over 80 °C) may cause an explosion. -
Page 24: Mantis_Cleaning
12. MANTIS_CLEANING External surfaces of MANTIS, that is to say the housing, protector of the LCD screen can be cleaned when it is necessary. Make sure the unit is closed, the power cord is disconnected and the batteries are removed. Disconnect all cables and connectors and check that the protectors rubber are closed on all external MANTIS port. -
Page 25: Mantis Technical Specifications
13. MANTIS_TECHNICAL SPECIFICATIONS G E N E R A L C O N N E C T I C Size 337mm x 235mm x 111mm 3 optocoupled bi-axe Encoder Input* quadrature or clock + dir Operating temperature 0 to 40°C Synchro Input Output* 2 TTL inputs Storage temperature... - Page 26 Contact us Any questions : support-m2m@eddyfi.com Hardware problems with your unit : MaintenanceEddyfiEurope@eddyfi.com...
