LEFT HANDLEBAR CONTROL
1
5
1
Clutch Lever
When pulled in, the clutch is disengaged. The engine
can be started in gear, when this lever is pulled in.
Slowly release to engage the clutch and move
forward. Pull in and apply the brakes to stop.
2 Main Beam/Dip Switch
T oggle between Main and Dipped headlight
beam to avoid dazzling oncoming traffic. When
main beam is selected the blue light will
illuminate on the tachometer. (see P8)
2
3
4
Turn signal operation
3
Moving the switch to the "
flash the left turn signal. Moving the switch to the
" " position will flash the right turn signal.
The green indicator light on the tachometer will
also flash intermittently. (see P8)
Horn button
4
Press the button to sound the horn.
Pass button
5
Press the button to flash the
headlight when overtaking.
Always use the indicators prior to changing
direction or turning, but do not forget to cancel
them after your manoeuvre.
9
" position will
WARNING!
Risk of injury.
