Otter Pro XT Cabin
Installation and Set-Up Instructions
Otter Pro XT Cabin
Fits Medium Otter Pro and Otter II Sled Only
Parts Identification and Check List
Description
Description
Description
Description
Description
Sled - Dark Gray
Tent XT Pro Cabin
Frame Bracket "A"
Frame Bracket "B"
Back Wind Support Bar - 48"
Center Wind Support Bar - 25 5/8"
Center Wind Support Bar - 40 1/2"
Adjustable Front Wind Support Bar
Main Frame Extension Bar - 25 3/8"
Main Frame Extension Bar - 27 9/16"
Main Frame Extension Bar - 26 1/16"
Outer Main Frame Bar - 29 3/4"
Outer Main Frame Bar - 28 1/2"
Middle Main Frame Bar - 43"
Seat with Swivel
Seat Bracket
Seat Base
Seat Rail - 58"
Seat Rail Cap
Seat Rail Bracket
Sleeve
#8 x 3/4" Self Tapping Screw
Black Plug
Black End Cap
5/16 Washer
1/4 x 1/2 Philips Head, Counter Sunk Screw
1/4 x 3/4 Hex Bolt
1/4 Nylon Hex Lock Nut
5/16 x 2 Hex Bolt
5/16 Nylon Hex Lock Nut
1/4" Low Profile Nylon Lock Nut
3/8" Self Tapping Screw
Plastic Protector
Star Washer
Plastic Trim Lock Kit
26
27
28
29
30
3
6
7
11
Back &
Center
15
20
19
31
32
33
34
Page 1
1
4
5
8
12
Front
10
Front
14
All
9
Bottom
16
18
21
22
35
Instructions - 70760
2
Back
13
Center
Bottom
17
23
