Procedure, Cosel Power Supply, Retrofit Kit, DAC 2200
Approval:
Approving Authority
Manufacturing Engineer
Design Engineer
Quality Engineer
Author

Revision History

Revision
A
Initial release.
Page 1 of 9
Form # 117140-B
Larry Wong
Larry Wong
Name / Signature on file.
Description of Change
Signature
Date
Date
05/03/2007
Document No
126603 Rev-A

Advertisement

loading
Need help?

Need help?

Do you have a question about the DAC 2200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sea Tel DAC 2200

Summary of Contents for Sea Tel DAC 2200

  • Page 1: Revision History

    Procedure, Cosel Power Supply, Retrofit Kit, DAC 2200 Approval: Approving Authority Signature Date Manufacturing Engineer Design Engineer Larry Wong Quality Engineer Author Larry Wong Name / Signature on file. Revision History Revision Description of Change Date Initial release. 05/03/2007 Document No...
  • Page 2 Make sure you have been properly grounded with an EDS. 5.1.4 Cosel Power Supply Retrofit Installation Procedure Removal of existing DAC-2200 equipment. Unscrew face-plate screws and slide DAC 2200 out of rack 6.1.1 Remove all 4 face-plate screws Take off existing connections from the back (AC POWER, RF IN, ANTENNA, M&C, 6.1.2...
  • Page 3 Procedure, Cosel Power Supply, Retrofit Kit, DAC 2200 Unscrew top cover and remove by removing nine 6-32 screws. 6.1.3 Remove 3 screws on each side On the lower right hand corner next to the fan, there is a PC board. This is the PS that 6.1.4...
  • Page 4 Procedure, Cosel Power Supply, Retrofit Kit, DAC 2200 Remove the fish paper by unscrewing the screws in the stand-offs and remove the PS, 6.1.5 P/N 119668-7, by unscrewing the remaining 2 screws. Remove the 2 screws, washers, and stand-offs Unplug the red fan connection.
  • Page 5 Procedure, Cosel Power Supply, Retrofit Kit, DAC 2200 On the right side of the PS, as facing the DAC front panel, is a 2 pin connector, with 6.1.8 black and white wires that will be replaced. Remove the 2 pin connector from this...
  • Page 6 Procedure, Cosel Power Supply, Retrofit Kit, DAC 2200 6.2 Installation of the Cosel PS Connect the slip connectors, of P/N 1226601, by pushing the black and white wires to 6.2.1 the power switch with the black wire on the right and the white wire on the left side of the power switch, as facing the DAC back panel, like in step 6.1.9.
  • Page 7 Procedure, Cosel Power Supply, Retrofit Kit, DAC 2200 Screw the L-bracket, P/N 126568, to the left side of the Cosel PS using the provided 6.2.4 two M3 screws and washers in Bag A, as the PS connections facing away. Use the M3 screws &...
  • Page 8 Procedure, Cosel Power Supply, Retrofit Kit, DAC 2200 Use the 6-32 X 5/16” screws & washers in Bag B Replace the DAC top cover and screw it in with the nine 6-32 screws removed in step 6.2.7 6.1.3. Plug in the back connections with its corresponding connections as removed in step 6.2.8...
  • Page 9 Procedure, Cosel Power Supply, Retrofit Kit, DAC 2200 Appendix A Quantity Description 119745-116 M3 X 6 Pan Head Philips 114580-005 #4 Flat Washer 114588-145 6-32 X 1/4" Pan Head 114580-007 #6 Flat Washer 125343-6 Power Supply, Cosel PBA150F-24 126601 Cable, Cosel PS, 2200...
