- Page 1 Dia Cam DiaCam USB 2.0 Intraoral Camera DiaDent Group International 11 - 3871 North Fraser Way Burnaby, BC Canada V5J 5G6 t: 604.451.8851 f: 604.451.8865 e: diadent@diadent.com w: www.diadent.com...
-
Page 2: Table Of Contents
1. Introduction 1.1 Overview 1.2 System Parts 1.3 System Requirements 2. Safety Information 3. Installation 3.1 DiaCam Device Driver Installation 3.2 DiaCam Hardware Installation 3.3 DiaCam Uninstallation 3.4 Testing and Setting DiaCam with emAMCAP 4. Operation 4.1 Camera On-Off/ LED Brightness 4.2 Camera Focus... -
Page 3: Introduction
Overview PAGE 2 1.1 Overview DiaCam is an advanced USB 2.0 intraoral camera that is ergonomically designed with easy-to-operate buttons built right on the slim and lightweight hand-piece. DiaCam has the following features: • High resolution - 1.2 mega pixels •... -
Page 4: Safety Information
• DiaCam is not autoclavable. • Beware of electromagnetic radiation generated from other electrical appliances, as they may cause DiaCam to malfunction • Do not operate DiaCam with devices that do not comply with EN 6060-1 and EN 6060-1-2 medical equipment standards... -
Page 5: Installation
Dia Cam Installation PAGE 4 ! ! ! Please install DiaCam USB device driver BEFORE connecting DiaCam into the USB 2.0 port. 3.1 DiaCam USB Device Driver Installation Step 1. Open the “DiaCam USB2.0 Device Driver” folder Step 2. Double Click on “Setup.exe”... -
Page 6: Diacam Device Driver Installation
Dia Cam Installation PAGE 5 3.1 DiaCam USB Device Driver Installation Step 5. Click on “Yes” to continue Step 6. Click on “Finish” to complete the installation. Rebooting your computer at this point is recommended 3.2 DiaCam Hardware Installation Step 1. Connect the USB cable... -
Page 7: Diacam Hardware Installation
Dia Cam Overview PAGE 6 3.2 DiaCam Hardware Installation Step 2. Check “Install the software automatically” and click on “Next” to proceed Step 3. Click on “ Continue Anyway” when Windows XP logo testing message appears Step 4. Click on “Finish” to... -
Page 8: Diacam Uninstallation
To uninstall the DiaCam device driver: Run the installation CD Double Click on “setup.exe” Select “Remove” to proceed uninstallation 3.4 Testing and Setting DiaCam with emAMCAP (Optional) Step 1. Double click on the “emAMCAP” icon Step 2. Go to the “Options” pull- down menu and click on “Video... -
Page 9: Operation
Dia Cam Operation PAGE 8 4.1 Camera On-Off/LED Brightness Camera on-off and its LED brightness are both controlled by the On-Off button on the hand-piece. The functions of the On-Off button are summarized in the table below: HAND-PIECE CAMERA STATUS OUTPUT STATUS OPERATION Camera On... -
Page 10: Camera Focus
PAGE 9 4.2 Camera Focus DiaCam features an adjustable focusing mechanism that allows a depth of field from 6mm up. Adjust the relative distance of the hand-piece and slide the focusing switch to obtain a focused image on an area of interest. -
Page 11: Warranty
Defects or malfunctions that are consequences of material failure or manufacturing errors can be repaired with no charge at our service department within the warranty period. DiaDent cannot accept any liability or provide any service for DiaCam in case of: • Noncompliance with this operations manual •... - Page 12 Dia Cam DiaDent Group International 11 - 3871 North Fraser Way Burnaby, BC Canada V5J 5G6 t: 604.451.8851 f: 604.451.8865 e: diadent@diadent.com w: www.diadent.com...
