- Page 1 GPRS/GSM Wireless Temperature & Level Measurement Terminals User Manual (HPT619) HOLYKELL TECHNOLOGY CO.LTD V2.4...
- Page 2 1. Summarize GPRS wireless temperature and level measurement terminals, It can regularly measuring the temperature and the pressure of the liquid, location latitude and longitude information, It sends measure value to the LLM server through the GPRS. The terminal will send an SMS message to user's phone number when GPRS network is disconnected.
- Page 3 3. Structure Drawing (1)Positive side structure diagrams, as shown in figure 1. Figure 1 (2)On the back of the chart, as shown in figure 2. Figure 2 4. LCD display and keys operating instructions 4.1 LCD display The LCD will display the current pressure measurement values of liquid when no keys press.
- Page 4 4.2 keys operating instructions “SET”、“ ” and“ ”buttons are placed on the terminal. User can use these buttons when the terminal running in Set Mode and don‟t send any data by SMS at the moment. The menu have Four functions: 1) “AS ”: set Terminal address.
- Page 5 storage and at the same time enter Units set menu, the press “ ” key to change unit and short press “SET” key storage and long press “SET” key to back “FS” menu or continue long press “SET” key to back pressure/level reading windows.
- Page 6 (3)Avoid the GSM antenna close to the metal objects or strong magnetic objects. (4)If the Terminal works fault, and you don‟t resolve the fault, please contact HOLYKELL. We don‟t allow user take down and repair the Terminals.
- Page 8 2. After loading and desk display 3. Open LLM Wireless Pressure/Level/Temperature Monitor Software...
- Page 9 4. Setting TCP/IP Listen IP and Port: (Here IP is your locally pc IP address, such as below 172.16.2.129. not means Server IP! Port must be the same as SMS configuration into Terminals. Also support database building.) 5. Terminal Setting: Likes Terminal Name/ID/Data transfer mode/interval time and so on.
- Page 10 Alarm setting and Liquid Density setting (if use for different medium measurement). #Attention: Above setting and configuration must done on ‘configuration mode’. 6. Search historical data record:...
- Page 11 7. Search historical alarm data record:...
