Dovpo Guardian 1.5 User Manual

Temperature control
Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the Guardian 1.5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dovpo Guardian 1.5

Summary of Contents for Dovpo Guardian 1.5

  • Page 3: Temperature Control

    Temperature Control Size: 100.0mm*57.0mm*28.5mm Material: Zinc alloy and silica gel...

  • Page 4: Specification

    Specification 1. Operating Voltage: 6.4V - 8.4V. 2. Maximum Output Current: 40A. 3. Operating Wattage: 5.0W - 150.0W 4. Temperature Control Mode Available 4.1 Temperature Control is available when using Nickel 200 coil as well as Titanium coil. 4.2 Nickel 200 coil and Titanium coil working resistance range: 0.05Ω - 1.0Ω. 4.3 Temperature control range: 200°F - 600°F/100℃...
  • Page 5 Operation Guide 1.ON/OFF Battery Switch By pressing the fire button 5 times quickly, the screen will display “DOVPO” logo.It leads you to main interface. See picture 1.1(In Ni 200 coil temperature control mode). See picture 1.2(In Titanium coil temperature control mode).
  • Page 6 Operation Guide 3.2 When in the main interface, press the fire button 5 times quickly then the device will be in Lock Mode. In this mode holding the fire button until the screen display " GOOD BYE! ", device shutdown. 4.Start Vaping 4.1 When in wattage mode, by pressing the fire button, the main screen will display voltage in the bottom right corner, will display the wattage in the middle.
  • Page 7 Operation Guide 0.60Ω 0.21Ω 0.50Ω 54.0 5.70V 3.07V 3.50V ℉ ℉ 19.8W 18.7W - - -℉ Picture 4.1 Picture 4.2 Picture 4.3 5.Wattage Settings When in wattage mode, using the “+” or “-” button will allow you to increase or decrease desired wattage by 1.0W.
  • Page 8 See picture 9.1. To read a correct resistance value please ensure the Nickel coil or Titanium coil is under ambient temperature before activating the Guardian 1.5; There is no need to lock the initial resistance if it's a same atomizer.
  • Page 9 Operation Guide 10. Lock Mode Turn on Lock Mode by pressing fire button 5 times quickly. All functions will be disabled in Lock Mode. Screen displays “LOCKED CLICK 5X” when you press any key. To turn off Lock Mode, please press fire button 5 times quickly. 11.
  • Page 10 13.6 When in temperature control mode, every time you put a new atomizer into the Guardian 1.5 you should lock the initial resistance first before firing. 13.7 Before lock the initial resistance please ensure the Nickel coil or Titanium coil is under ambient temperature before activating the Guardian 1.5, or it may...
  • Page 11 If the setted wattage is low, the temperature in vaping may increase slowly or can not meet the setted temperature. 13.9 To ensure constant temperature for the coil, the Guardian 1.5 will automatically adjust its output power to meet the desired temperature. The device will prevent the coil from being damaged by a higher than desired temperature scenario caused by low juice volume or other reasons.
  • Page 12 Operation Guide 16.Short Circuit Protection 16.1 If the atomizer has a short circuit, the screen will show “ATOMIZER SHORT” when pressing the fire button 16.2 The device will restart if a short circuit happens during working, the screen will display “OVER CURRENT”. It also could be caused by excessive instantaneous current.
  • Page 13 Operation Guide 21. The screen will display “TEMPERATURE PROTECT” if temperature of the coil gets too high. 22. For safety, it is recommended to use two batteries of the same power, capacity, and discharge rate. We also recommend you to marry these batteries and use the pair together at all times.
  • Page 14 Operation Guide Picture 24.1 Picture 24.2 REMARK Please use the battery with good insulation. It is not recommended to use battery with broken insulation. See picture below.

  • Page 15: Operating Instructions

    Operating Instructions 1. Please use all the accessories in right way to avoid any damage which may be caused by incorrect usage. 2. Please use the original charge cable or the 18650 battery charger when charging. 3. When not using your device for a long period of time, please turn off the system, remove the batteries and store it in a dry, safe place to avoid damage.
