ENIGMA II
SLIDE CONTROL
Owner's Book
INCLUDES USER, INSTALLATION & MAINTENANCE
INSTRUCTIONS
Please read these instructions carefully before you start using the
appliance
Keep this booklet handy for future reference
This appliance is
for use in GREAT BRITAI or IRELA D only
A QUALITY PRODUCT FROM C&J FIRES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENIGMA II SLIDE and is the answer not in the manual?

Questions and answers

Related Manuals for FDC ENIGMA II SLIDE

Summary of Contents for FDC ENIGMA II SLIDE

  • Page 1 ENIGMA II SLIDE CONTROL Owner's Book INCLUDES USER, INSTALLATION & MAINTENANCE INSTRUCTIONS Please read these instructions carefully before you start using the appliance Keep this booklet handy for future reference This appliance is for use in GREAT BRITAI or IRELA D only A QUALITY PRODUCT FROM C&J FIRES...

  • Page 2: Table Of Contents

    ENIGMA II SLIDE Instructions CONTENTS PAGE User Instructions SECTION ONE Introduction Consumer Protection Health and Safety Introduction SECTION TWO Operation SECTION THREE Fuel Bed Cleaning and Layout Coal Layout Pebble Layout SECTION FOUR Important information INSTALLATION INSTRUCTIONS SECTION FIVE Specification...

  • Page 3: User Instructions

    ‘hazardous waste and should be disposed of at a site licensed for the disposal of industrial waste. INTRODUCTION The ENIGMA II SLIDE is a decorative fuel effect appliance with a radiant heat conserver box for improved efficiency. The ENIGMA II SLIDE is designed and tested to the requirements of EN 509 The ENIGMA II SLIDE should be installed and serviced by a competent person i.e.

  • Page 4: Section Two Operation

    The ENIGMA II SLIDE incorporates a single gas control, which selects ignition pilot, and main burner low and high settings. The ENIGMA II SLIDE incorporates a safety device in the form of an Oxygen Depletion System, which constantly monitors the oxygen in the room and will cause the fire to switch off if the oxygen level reduces, for instance due to insufficient ventilation or a blocked flue.

  • Page 5: Section Three Fuel Bed Cleaning And Layout

    ENIGMA II SLIDE Users Instructions SECTION THREE Fuel Bed Cleaning and Layout Important: - Refer to the ‘Health & Safety Notice located on page 3 of this booklet before cleaning or replacing any refractory material. The fuel bed components are delicate and they should be handled with great care.
  • Page 6 ENIGMA II SLIDE Users Instructions SECTION THREE Fuel Bed Cleaning and Layout Cont. • Lay 7 35mm x 35mm coals into the front of the burner tray. They can have the backs against the burner slot but DO NOT place on top of the burner slot.
  • Page 7 ENIGMA II SLIDE Users Instructions SECTION THREE Fuel Bed Cleaning and Layout Cont. • Add 5 55mm x 55mm coals on the front row resting between the 35mm coals and 45mm coals already placed. as shown. Place the end 2 square to the firebox sides and place the middle 3 at an angle.

  • Page 8: Pebble Layout

    ENIGMA II SLIDE Users Instructions SECTION THREE Fuel Bed Cleaning and Layout Cont. FUEL BED LAYOUT (PEBBLE OPTION) FUEL BED COMPONENTS • 12 off 45mm ripped coals for firebed base • Pebbles in colours as below:- Pebble Pebble qty identification...
  • Page 9 ENIGMA II SLIDE Users Instructions SECTION THREE Fuel Bed Cleaning and Layout Cont. • Place 4 45mm x 45mm coals on the flat part of the base board with the smooth faces upwards. Push them back against the joint between the boards. DO NOT...
  • Page 10 ENIGMA II SLIDE Users Instructions SECTION THREE Fuel Bed Cleaning and Layout Cont. • Place 2 x large round pebbles and 1 x heart shaped pebble as shown. Place them touching the front row. Do not let them fall into the gaps between the...

  • Page 11: Section Four Important Information

    ENIGMA II SLIDE Users Instructions SECTION FOUR Important Information The only user removable parts are: - • The loose pebbles or coals. • The baseboards • Cast Fret • Decorative Trim Like all appliances incorporating an aerated burner a low frequency noise may be heard, particularly on the low setting, this is quite normal and does not affect the operation of the appliance.

  • Page 12: Installation Instructions

    Installer in accordance with the current Gas Safety (Installation and Use) Regulations 1998 (as amended). Failure to do so could lead to prosecution. • This ENIGMA II SLIDE is for use ONLY with the GAS STATED ON THE DATA BADGE. CHECK YOU HAVE THE CORRECT APPLIANCE FOR THE GAS YOU ARE USING.

  • Page 13: Section Seven Siting The Appliance

    ENIGMA II SLIDE Installation Instructions SECTION SIX Regulations and Warnings Continued The following are the relevant Codes of Practice and British Standards: - BS 5871 BS 8303 1986 BS 5440 part 1 1990 BS 1251 1987 BS 6891 1988 BS 6461 parts 1 & 2 1984 BS 715 1989 BS 1289 part 1&...

  • Page 14: Class Two Fabricated Metal

    ENIGMA II SLIDE Installation Instructions SECTION SEVEN Siting the Appliance Continued • CLASS TWO FABRICATED METAL A double-walled or insulated metal flue box built to the requirements of BS 715 with an insulated flue having a minimum diameter of 125 mm (5 ins) and a minimum effective overall height of 3 metres (10 ft).

  • Page 15: Clearance To Side Of Fire

    ENIGMA II SLIDE Installation Instructions SECTION EIGHT Fireplace Requirements Continued CLEARANCE TO SIDES OF FIRE Minimum width between vertical sides of combustible surround should not be less than 700mm provided fire is central to surround and sides do not project more than 150 mm. When vertical side forward projection is increased by 12.5 mm add 50 mm to inside width of surround.

  • Page 16: Preparing The Appliance For Gas Connection

    ENIGMA II SLIDE Installation Instructions SECTION NINE To Install the Appliance Contrinued PREPARING THE APPLIANCE FOR A GAS CONNECTION If it is intended to be a concealed connection the 8mm supply should be positioned in the opening first. The pipe should be positioned so that when the appliance is pushed back into the opening it enters the grommet hole at least 180mm, taking into account the requirements of BS 6891 1988 dealing with enclosed pipes.

  • Page 17: Gas Connection From The Front

    ENIGMA II SLIDE Installation Instructions SECTION NINE To Install the Appliance continued GAS CONNECTION FROM THE FRONT Connections may be made from the front of the appliance from either the left or right in 8-mm diameter pipe. If a left-hand connection is required the tube should be routed below the gas control and onto the inlet elbow.

  • Page 18: Checking Gas Soundness

    ENIGMA II SLIDE Installation Instructions SECTION NINE To Install the Appliance Continued CHECKING GAS SOUNDNESS After completing the gas connection to the appliance, check for gas soundness in accordance with current codes of practice. CONNECTING CONTROL LEVER Flip the slide control lever...

  • Page 19: Checking Operation Of Fire

    ENIGMA II SLIDE Installation Instructions SECTION NINE To Install the Appliance Continued CHECKING OPERATION OF FIRE Remove the screw from the pressure test point on the inlet elbow and fit pressure gauge. Turn on gas to the appliance. Purge the air from the appliance by holding the control lever down to allow the air in the pipe-work to be purged and the spark generator to ignite the pilot.

  • Page 20: Maintenance Instructions

    ENIGMA II SLIDE Maintenance Instructions SECTION TEN Maintenance Instructions GENERAL Servicing should be carried out annually by a competent person such as a CORGI-registered person in accordance with the current Gas Safety (Installation and Use) Regulations 1998 (as amended), this should ensure the safe and correct operation of the appliance.

  • Page 21: Replacement Of Burner And Or Silencer

    ENIGMA II SLIDE Maintenance Instructions SECTION TEN Maintenance Instructions continued REPLACEMENT OF BURNER AND OR THE SILENCER NOTE: The silencer must not be modified and must be correctly positioned in its bracket. The burner can be slid to the right side for a pebble fuel bed to ensure maximum aeration.
  • Page 22 For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. Model: Enigma II Slide Serial No. This information can be found on the label attached to the packaging and on the data badge, which is located on the appliance flange, top right behind trim.
  • Page 23 Post Code TELEPHONE No. PRODUCT DETAILS Model: ENIGMA II SLIDE Serial No. Date of Purchase This information can be found on the label attached to the packaging and on the data badge, which is located on the appliance flange, top right behind trim.
  • Page 24 Enigma II Slide Packing – Coal Enigma II Slide Packing – Pebble Product Product Serial No Serial No A0009 A0010 ID Label ID Label Prefix Prefix Burner Tray / Box Assembly Burner Tray / Box Assembly Ceramics Set (4287) Ceramics Set (4324)
