- Page 1 ENIGMA II SLIMLINE SLIDE OWNER'S MANUAL Please read these instructions carefully before you start using the appliance Keep this booklet handy for future reference This appliance is for use in GREAT BRITAIN or IRELAND only...
-
Page 2: Table Of Contents
ENIGMA II SLIMLINE SLIDE Owner's Manual CONTENTS PAGE USERS INSTRUCTIONS SECTION ONE Important Information SECTION TWO Operating the Appliance SECTION THREE Fuel Bed Layout SECTION FOUR Cleaning SECTION FIVE General Points INSTALLATION INSTRUCTIONS SECTION SIX Appliance Data SECTION SEVEN Regulations & Warnings... -
Page 3: Section One
This appliance is intended for decorative purposes. • The ENIGMA II SLIMLINE SLIDE is designed and tested to the requirements of the EN 509. • The appliance is for use on Natural Gas only and should be installed by a competent person i.e. -
Page 4: Section Two
Important Information Continued INTRODUCTION The ENIGMA II SLIMLINE SLIDE incorporates a single gas control, which selects ignition pilot, low or high settings. It is operated via a slide lever on the upper right hand side of the appliance. The appliance incorporates a safety device in the form of an Oxygen Depletion System, which constantly monitors the oxygen in the room and will cause the fire to switch off if the oxygen level reduces, for instance due to insufficient ventilation or a blocked flue. -
Page 5: Section Three
ENIGMA II SLIMLINE SLIDE Users Instructions SECTION THREE Fuel Bed Layout It is important that all the fuel bed and moulded shapes are positioned as shown in these instructions. Two Alternative Fuel beds are available: - A) Coal B) Pebble Identify the fuel bed and assemble as shown below. - Page 6 ENIGMA II SLIMLINE SLIDE Users Instructions SECTION THREE Fuel Bed Layout Continued • Place six coals on the top of the front matrix as shown. Arrange to coals to have rough sides forward and make sure that they are stable in their positions.
- Page 7 ENIGMA II SLIMLINE SLIDE Users Instructions SECTION THREE Fuel Bed Layout It is important that all the fuel bed and moulded shapes are positioned as shown in these instructions. PEBBLE FUEL BED Some soot deposits will form on the pebbles, this is perfectly normal and adds to the realism of the appliance.
- Page 8 ENIGMA II SLIMLINE SLIDE Users Instructions SECTION THREE Fuel Bed Layout Continued • Place five large pebbles as shown. So that they sit on the Front Matrix in the indents provided. Check that they are stable against the rear matrix by putting slight pressure on them with your fingers.
-
Page 9: Section Four
Low setting, this is quite normal and does not affect the operation of the appliance. It is advised that the ENIGMA II SLIMLINE SLIDE OR 4 TC Lo fire is serviced annually this is more likely to provide trouble-free operation. -
Page 10: Installation Instructions
ENIGMA II SLIMLINE SLIDE Installation Instructions SECTION SIX Appliance Data Category of appliance: Category Overall dimensions: Height 605mm (or 555mm for the Lo version) Width 505mm Forward Projection: 75mm, (From fireplace opening including fret.) Weight: 11kg (Boxed excluding fret) 16.5kg (with fret) 9.5kg (Unboxed excluding fret) - Page 11 ENIGMA II SLIMLINE SLIDE Installation Instructions SECTION SEVEN Regulations and Warnings Cont. THE FOLLOWING ARE RELEVANT CODES OF PRACTICE AND BRITISH STANDARDS: - BS 5871 BS 8303 BS 5440 PART 1 BS 1251 BS 6891 BS 6461 PARTS 1 AND 2...
-
Page 12: Section Eight
ENIGMA II SLIMLINE SLIDE Installation Instructions SECTION EIGHT Siting the Appliance Spacers are available in the following sizes 42mm, 30mm and 20mm these may be used to reduce the minimum depth required. The fire can be installed in the following flues and locations:- •... -
Page 13: Class Two Fabricated Metal
ENIGMA II SLIMLINE SLIDE Installation Instructions SECTION EIGHT Siting the Appliance Continued • CLASS TWO Fabricated metal A double-walled or insulated metal flue box built to the requirements of BS 715 with a minimum diameter of 125 mm (5 ins) and a minimum effective overall height of 3 metres (10 ft). -
Page 14: Section Nine
ENIGMA II SLIMLINE SLIDE Installation Instructions SECTION NINE To Install the Appliance CHECKING THE FLUE AND FIRE OPENING • Check that the chimney conforms to the required specifications as previously stated. Examine the condition and carry out any remedial work. -
Page 15: Fixing Back To Opening
ENIGMA II SLIMLINE SLIDE Installation Instructions SECTION NINE To Install the Appliance Continued Cut a cross slit in the rubber grommet and feed the appliance onto the 8mm-gas supply pipe. Check for gas soundness. Reconnect the bell Position the restrictor elbow supplied and mark crank mechanism as above ensuring that the supply pipe at its cut off length. -
Page 16: Optional Cable Fixing System
ENIGMA II SLIMLINE SLIDE Installation Instructions SECTION NINE To Install the Appliance Continued FIX 4 OFF EYE OPTIONAL CABLE FIXING SYSTEM IN POSITIONS It is recommended that the appliance be secured to SHOWN the fireplace fascia with screws and wall plugs supplied. -
Page 17: Check Burner Pressure And General Operation
ENIGMA II SLIMLINE SLIDE Installation Instructions SECTION NINE To Install the Appliance Continued Connect the link lever to the stud at the end of the slide control lever and replace the nylock nut. IMPORTANT TURN THE NUT UNTIL IT JUST TIGHTENS AND THEN TURN IT BACK A HALF TURN. -
Page 18: Section Ten
ENIGMA II SLIMLINE SLIDE Installation Instructions SECTION TEN Checking Operation of Fire Checking Product Clearance • Check for satisfactory clearance of combustion products, close all doors and windows and leave fire burning for five minutes. CLOSE ALL DOORS AND WINDOWS, LEAVE FIRE BURNING FOR TEN MINUTE POSITION HEAD OF SMOKE MATCH UNDER FIRE OPENING AS SHOWN •... -
Page 19: Section Eleven Maintenance
ENIGMA II SLIMLINE SLIDE Maintenance Instructions SECTION ELEVEN Maintenance • Servicing should be carried out annually by a competent person such as a CORGI-registered person in accordance with the relevant regulations, to ensure the safe and correct operation of the appliance. -
Page 20: Replacement Of Silencer
ENIGMA II SLIMLINE SLIDE Maintenance Instructions SECTION ELEVEN Maintenance Cont. Replacement of Injector 1. Repeat operations 1-12 for removal of gas control. 2. Undo injector Lock nut and remove the silencer support plate and injector. 3. Clean or replace injector. - Page 21 LT4935 (1:01/08)
- Page 22 Important For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. Enigma II Slimline Slide Serial No. Model: This information can be found on the label attached to the packaging and on the data badge, which is located on the appliance flange, top right behind trim.
- Page 23 Post Code TELEPHONE No. PRODUCT DETAILS Model: Enigma II Slimline Slide Serial No. Date of Purchase This information can be found on the label attached to the packaging and on the data badge, which is located on the appliance flange, top right behind trim.
