1 Power connector
2 Power switch
3 Type A USB2.0 ports
4 DVI port (monitor)
5 Type A USB3.0 ports
6 Network port
7 Command interface port
You can now turn on your Fiery proServer.
Fiery Quick Touch
You can use the Fiery Quick Touch LCD on the front of the Fiery proServer to shut down, reboot, or restart the Fiery
proServer, or change the brightness setting of the LCD.
By default, Fiery Quick Touch displays Idle after startup, which indicates that no jobs are currently being processed.
To display the Fiery Quick Touch main menu, press the ellipsis icon (three dots) at the top right of the display.
