Installation Instructions for LV303, 304,305, 306, 307, 308, 309 and LV310

Lampholder Installation

1 Make sure power to the channel or wireway
has been turned off.
2 Install lamp with proper voltage for
system voltage used.
3 Hold lampholder as illustrated and insert
into channel.
4 Hold outside collar down while turning
lamp holder 90 degrees to engage channel.
Insert
Outer
Collar
Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • 770.486.4800 • FAX 770.486.4801
Twist 90°
