Honeywell INTEVIO RK-ZONE8 Product Instructions

Zone expander
Hide thumbs

Advertisement

Quick Links

INTEVIO-Zone Expander
Product Instructions
Model:RK-ZONE8
M_2000061160_UL_1.1
M_2000060504_EN_1.0

Advertisement

loading

  Related Manuals for Honeywell INTEVIO RK-ZONE8

  Summary of Contents for Honeywell INTEVIO RK-ZONE8

  • Page 1 INTEVIO-Zone Expander Product Instructions Model:RK-ZONE8 M_2000061160_UL_1.1 M_2000060504_EN_1.0...
  • Page 3 Precautions Danger This sign reminds users of “dangerous voltage” on the product. Caution This sign reminds users of important instructions attached to the product. In order to prevent electric shock, this equipment plug shall not be used as conductor to extend power supply Safety line.
  • Page 4: Important Safety Instructions

    Ventilation To offset heat generated by the unit, it is necessary to provide ample ventilation around the unit. Avoid blocking or impeding the ventilation holes on the unit. To prevent unnecessary problems, install the unit in a place free from any vibrations, direct sunlight, humidity or dust circulation. Prevent liquids or other materials to enter cabinet If the unit gets wet or any foreign material enters the amplifier cabinet, immediately disconnect the AC power cord and consult your dealer or...
  • Page 5: Network Security

     Use only with the cart, stand, tripod, bracket or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.  Unplug this apparatus during lightning storms or when unused for long periods of time.
  • Page 6 Password Precaution  Please change the password during the system deployment.  Users need to change the password regularly.  The password with six numbers is preferred.
  • Page 7: Product Overview

    Product Overview The RK-ZONE8 is the zone extension device to expand the number of loudspeaker zones and interfaces. RK-ZONE8 can provide the interfaces for 16 loudspeaker lines (corresponding to 8 zones), 8 dry contact inputs and 8 dry contact outputs. External power amplifiers must be connected to drive all the loudspeakers.
  • Page 8: Front Panel

    Functions  Main/backup power supply  DC power output  Zone control  Amplifier redundancy  Digital volume control  Fault supervision  Dry contact inputs & outputs Front Panel Button/Indicator Description Light Indicators for power supply, main power Device status fault, backup power fault, earth fault, CPU indicators fault, network fault, open circuit and short...
  • Page 9: Rear Panel

    Rear Panel Parts/Ports Description Channel 1 audio output connection. Audio output of CH1 Connecting to external power amplifier or third party devices. Channel 2 audio output connection. Audio output of CH2 Connecting to external power amplifier or third party devices. Audio input interface, used to connect to Line in external audio devices, such as CD/DVD...
  • Page 10 Parts/Ports Description Amplifier interface for connection to the Spare amplifier spare amplifier, transmit audio signal and interface self-test signal to power amplifier and receive the fault status from power amplifier. To set the device address for Address DIP switch communication, which ranges from 1 to 15. Mode switch To set the work mode.
  • Page 11: Technical Specifications

    Technical Specifications Parameters Values Main power supply AC 100V-240V 50/60Hz Backup power supply 21.5V DC - 28.5V DC Fuse T2AL 250V Power consumption Line Input Input signal 1V(0dBV) 10 KΩ Input impedance 80Hz-18KHz, ±3dB Frequency response 80dB, A-weighted Audio Output Output channels CH1, CH2 Output signal...
  • Page 12 Parameters Values Contact Input / Output Dry contact input 8 dry contact inputs with supervision Contact output 8 dry contact output (NO、NC and COM) Maximum voltage of the AC 250V/DC 30V outputs Maximum current of the 2.5A outputs Others DC Power output 24V/1A Working Conditions ...
  • Page 13: Packing List

    Packing List Components Qty. RK-ZONE8 Dry contact input terminal (3.81-10P) Dry contact output terminal (3.5-6P) Loudspeaker terminal (5.08-16P) Power amplifier terminal (5.08-2P) DC Power output terminal (5.08-2P) Backup power terminal (7.62-4P) Twisted-pair cable (2m) Audio cable AC power supply cable Fuse(2A) Product instructions Machine Legs...
  • Page 14 12 Clintonville Road, Northford, CT 06472, USA Tel: +1-800-323-4576 Manufacturer: Life Safety A/V (Guangzhou) Co., LTD No.257, Junye Road, Guangzhou GETDD, East 510530, China Tel: +86 (0)20 2839 9600 Fax: +86 (0)20 2820 8706 ©2017 Honeywell International Inc. All rights reserved.
