Egoman Technology MD398IFOD User Manual

Hide thumbs Also See for MD398IFOD:

Advertisement

Quick Links

Download this manual
0

Advertisement

loading
Need help?

Need help?

Do you have a question about the MD398IFOD and is the answer not in the manual?

Questions and answers

Related Manuals for Egoman Technology MD398IFOD

Summary of Contents for Egoman Technology MD398IFOD

  • Page 2 Note: Please recharge the MP4 player before using it!  Please use your digital player properly in case of explosion, fire, electric shock, etc. 1．Do not repair the player by yourself, or it will cause damage. 2．Do avoid getting the player wet or drop it in water. 3．Do not use the player while raining.
  • Page 3 Function features  The player supports MP3 and WMA format music files.  Support USB 2.0 capability, much faster than USB 1.1, to enable faster communication with your PC;  The player can record outside voice and FM radio;  The player has repeat functions, including A­B repeat function;...
  • Page 4 Accessories Installation CD USB Cable Earphones User Guide...
  • Page 5 Components and button functions Power on/off or play/pause MENU button Record/Volume Forward/Volume up Backward/Volume down LCD display Earphone jack HOLD button RESET hole/Microphone USB port Hang strip hole...
  • Page 6 Charging Li –polymer battery safely Connect the PC USB port and the player USB port with the provided USB cable. The power sign is shown dynamic when charging, once full charged, the power sign will stop moving, power is full, please shut off the power. The charging time is approximately 2 hours.
  • Page 7 one of the music files then press button to playback it. To return main menu: Press and hold M button. To Pause/Play: Short press button. To change tracks: Short press button. To turn unit off: Press and hold button. NOTE: Please reset your player by pressing the RESET hole while failing to power on or hanging up in power on mode.
  • Page 8 Delete files from the removable USB storage (use the "Delete" command). Remove the player from PC – please follow the steps in case of damaging the player or data loss. Click the left mouse button on the icon that is on the taskbar at the bottom right corner of the desktop.
  • Page 9 CAUTION:  Do not remove the player while files within the USB Mass Storage are being played on your computer.  Do not disconnect the player from your computer while transferring files, or it will cause damage to the player or data loss. Menu Navigation M button: Enter main menu, submenu or return.
  • Page 10 File Browse Select File Browse mode and short press button to enter. Short press buttons to select the audio files. Short press button to playback one of the audio file. Repeat Select Repeat mode and short press button to enter. Short press buttons to select one of the repeat modes: No Repeat, Repeat One, Repeat All, RandomAll, DirRepOne, DirRep, DirRanAll.
  • Page 11 Seconds, 30 Seconds, 60 Seconds Short press button to confirm, and it will playback slide show file after playback music for selected time. You can use slide show maker AP (open the provided CD and you will see the slide show maker AP) to make slide show files for our portable audio player chip.
  • Page 12 Make Slide Show 1. Required System: Windows 2000, XP, Vista 2. AP Operation: View of “Image File Name List” – Show all image input files. View of “Preview Window” – Show an image file or the effects of the slide show...
  • Page 13 Mode Selection – Four modes: Normal, Shutter (Left to Right), Shutter (Top to Down), Circle Command of “Load Image” – Input image files. (*.jpg, *.gif, *.bmp) Command of “Preview” – Show the effects of the slide show. Command of “Transform” – Transform all image input files to single slide show file. Command of “Cancel”...
  • Page 14 Short press buttons to select your desired speed (e.g. 1.00X, 1.14X, 1.33X, 1.60X, 0.50X, 0.67X, 0.80X). Short press button to confirm. NOTE: If the file is WMA format, it does not support “Play Rate” mode. Intro Select Intro mode and short press button to enter.
  • Page 15 Short press button to choose your desired recorded file Short press button to play the recorded file. Long press R/V button to enter record mode. Short press M button to save the recorded file, short press button to play the record file.
  • Page 16 Short press button to tune your desired stations (at intervals of 0.1 MHz). Press and hold R/V button to start recording FM. Short press M button to enter submenu (e.g. Preset, Auto Search, Manual Search, Save, Exit). Short press button to confirm. SETUP In main menu, short press buttons to select “SETUP“...
  • Page 17 Short press buttons to setup screen brightness or screen backlight time, you can select the screen backlight time: 5s, 10s, 30s, ON. Record Short press buttons to select Quality mode (e.g. High, Normal, Low). Sys Tools: Short press buttons to select your desired opinion (e.g. Format, Reset, Sys Info.) Format: Select “Quick”...
  • Page 18 Usage steps for conversion: Click “Input Video” column to select the video file you wish to convert for use on the...
  • Page 19 digital player. Select the “Advanced Setting” and setup the “Output Video Quality” (Include High Quality, Normal Quality, Medium Quality, Low Quality). Select “Output Frame Size” is 128x128 The default “Output Audio Quality” is Good. MTV video converter allows the user to replace the video clip audio track with an audio file of their own choice.
  • Page 20 MTV video converter allows the user to convert a segment of the selected video clip rather than the whole clip. To do this, drag the scroll bar and click the arrowhead on the front of the starting time and the finish time. To convert the whole input video file, go straight to step 7 To proceed with the conversion process simply deselect the “MTV Preview”...
  • Page 21 Select one of the MTV files by pressing button. Short press button to playback the MTV file. EBOOK In main menu, short press buttons to select EBOOK mode. Short press button to enter into. Short press buttons to choose your desired .TXT file Short press button to browse your desired file.
  • Page 23 (4) Click “Next>” to enter into next step.
  • Page 25 Close the Driver (X:) window, then click “OK” to finish setup process and restart your computer now, then you can use the MP4 player.
  • Page 26 2. Format the player The player is “FAT” format. If you wish to format it, right click removable disk and choose “Format” mode, then click “Start” to format in operating system. As following pictures show: Notice  Please setup the HOLD button in “unlock”...
  • Page 27 Technical Specification Name Description Capacity of Flash Build­in Flash Memory, up to 8G. Memory USB Interface USB2.0 (High Speed) LCD Display 1.5’CSTN Power supply Li­Polymer ≥85dB S/N ratio Audio Frequency Range 20Hz – 20kHz NORMAL, POP, ROCK,CLASSIC, JAZZ, BASS, Custom EQ Support files format MP3, WMA, MTV and JPG, etc.
