Egoman Technology MD398IFOD User Manual

Hide thumbs Also See for MD398IFOD:

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the MD398IFOD and is the answer not in the manual?

Questions and answers

Related Manuals for Egoman Technology MD398IFOD

Summary of Contents for Egoman Technology MD398IFOD

  • Page 2 Digital Player...

  • Page 3: For Your Safety

    For your safety ─ Read this user guide carefully to ensure proper use of the product and to avoid any danger of physical damage. Use Safely...
  • Page 4 Note: Please recharge the digital player before using it! Function features  The player supports MP3, WMA and WAV format music files. Including WMA files with DRM (Digital Rights Management) function.  Support USB 2.0 capability, much faster than USB 1.1, to enable faster communication with your PC.
  • Page 5 Components and Button functions Play/Pause/Confirm Backward/Previous song Forward/Next song Volume up/Previous Volume down/Next LCD display LOCK button Record/A­B repeat MENU button Power on/off RESET/Microphone Speaker Micro SD/T­flash card slot Earphone jack USB port...
  • Page 6 Button Definition Turn power on/off Press and hold to turn power on/off Play/Pause/Confirm Press to play/pause/confirm Previous song/Backward Next song/Forward Press to turn to previous one/next one In playback mode, press and hold for backward/forward Adjust the volume Press to turn up/turn down the volume Press to previous one/next one R/A­B Record/A­B repeat...
  • Page 7 RESET hole & Microphone You can reset the system setup of your player by pressing the RESET hole. It is used for recording the outside voice or FM radio while the player is playing record function. Micro SD/T­flash card slot Support Micro SD/T­flash card. Note: Please do not install or pull out the Micro SD/T­flash card while your player is in power on state.
  • Page 8 Do not disassemble, crush, short­circuit or incinerate your battery as it may cause fire, injury, burns, or other hazards. Basic operations Turn power on and play music Connect earphone to earphone jack; Switch HOLD button to unlock position; Press and hold button to turn on and enter main menu (the default menu is “Music”...
  • Page 9 Ⅰ. Open files/folders to transfer from your computer. Ⅱ. Open My Computer → Removable Disk from the desktop. Ⅲ. Select the files/folders to transfer from your computer and draw and put them to a folder of your choice in the Removable Disk (you also can transfer files on your PC to the player using the "Copy"...
  • Page 10 Click the left mouse button on the icon that is on the taskbar at the bottom right corner of the desktop. Click the "Safely remove USB Mass storage Device – Drive (X:)" column. Disconnect the player from your computer. CAUTION: ...
  • Page 11 select your desired mode (e.g. Repeat, Equalizer, 3D, Play Rate, File, Classified, Play List, Slide Show). Repeat Select Repeat mode and short press button to enter. Short press 【 】 buttons to select your desired option (e.g. No Repeat, Repeat One, Repeat All, Random All, Folder Normal, Folder Repeat, Folder Random).
  • Page 12 Select Play Rate mode and short press button to enter. Short press 【 】 buttons to select your desired speed (e.g. 1.00X, 1.14X, 1.33X, 0.67X, 0.80X). Short press button to confirm. NOTE: If the audio file is WMA format, it does not support “Play Rate” mode. File Select File mode and short press button to enter.
  • Page 13 NOTE: ClassifyMusic_V1.5 will download music files into Root\MUSIC folder automatically. AP Usage Step: 1. Connect your player to the PC (Require the PC operating system: Windows 2000, XP, Vista). 2. Put CD disk into the CD driver and open “ClassifyMusic_V1.5” folder. 3.
  • Page 14 Download music files to the player. 1). Click “Select Music” command to input music files (*.mp3, *.wma formats). Click ”Download Music” command to download selected music into the device and create/refresh music classification database. Click “Delete Music” command to delete music files on the device side and create /refresh music classification database.
  • Page 15 NOTE: The “ClassifyMusic_V1.5” AP only can classify music files within the internal flash; About the detailed introduction to the Classify Music AP, please refer to: CD dis k→ ”ClassifyMusic_V1.5” folder→“Music_Classification_AP” word format file. Play List Press button to enter and you can see the play list (My List, *pla, *m3u, *wpl), open one of the play list and select the music files, then you can press button to playback NOTE:...
  • Page 16 NOTE: The player just can playback one slide show file, so put one SLS file into the SLS.DIR folder at one time. Slide Show AP Usage: Make Slide Show 1. Required System: Windows 2000, XP, Vista 2. AP Operation: View of “Image File Name List” – Show all image input files. View of “Preview Window”...
  • Page 17 Down), Circle Command of “Load Image” – Input image files. (*.jpg, *.gif, *.bmp) Command of “Preview” – Show the effects of the slide show. Command of “Transform” – Transform all image input files to single slide show file. Command of “Cancel” – Cancel preview or transformation. Command of “Delete”...
  • Page 18 】button to tune FM frequency between In “Normal” mode, short press【 87.5MHz and 108MHz. (At intervals of 0.1 MHz); Or in “Preset” mode, Press【 】button to select the preset stations (Total 30 preset stations). Short press MENU button to enter submenu: Save Preset, Auto Scan. You can press and hold R/A­B button to start recording FM stations, and press MENU button to save the FM recorded file.
  • Page 19 】buttons to select Press R/A­B button to enter “delete” menu, and press【 “No” or “Yes”, then press button to confirm. Press MENU button to return to photos list, select one of the photos and press button to browse it. Short press button again to browse all photos at interval of 3 seconds, or press 【...
  • Page 20 Usage steps for conversion: Click “Input Video” column to select the video file you wish to convert for use on...
  • Page 21 the digital player. Select the “Advanced Setting” and setup the “Output Video Quality” (Include High Quality, Normal Quality, Medium Quality, Low Quality). Select “Output Frame Size” The default “Output Audio Quality” is Good. MTV video converter allows the user to replace the video clip audio track with an audio file of their own choice.
  • Page 22 MTV video converter allows the user to convert a segment of the selected video clip rather than the whole clip. To do this, drag the scroll bar and click the arrowhead on the front of the starting time and the finish time. Click the folder icon on the right of the video output path, then you can select the converted file output path as your opinion.
  • Page 23 Click “Start Conversion” button to convert video file. Play MTV Video files In main menu, short press 【 】 or 【 】 button to select “Video“ mode and enter by pressing button. Short press MENU button to enter submenu: Repeat, Video OSD Color, and enter the submenu by pressing button.
  • Page 24 Short press button to browse your desired file. 】buttons to turn to previous or next page. Short press【 Short press MENU button to return to E­book catalog Press and hold MENU button to return to main menu. Note: User can use the E­BOOK function to browse .TXT files. FILE In main menu, short press 【...
  • Page 25 DRM 10(optional function) What is DRM? Stands for digital rights management, a technology used to protect digital products from copyright infringement. When a customer buys a DRM­protected music download, the download is encrypted specifically for that customer. To allow the customer to use the file on a separate digital player they must link the DRM enabled player to Windows Media Player 10 and link both applications.
  • Page 26 NOTE: There are 2 ways to set your player into MTP mode (1) In “USB Mode” select “MTP mode” mode and short press button to confirm. (2) After connecting the player with your PC, press and hold button for 6 seconds to switch between “MSC mode”...
  • Page 27 Click “OK” to start synchronization, your PC will display: Select “Manual” or “Automatic” as your requirement, for example, select ”Manual” and click “Finish”, it will display:...
  • Page 28 Add the songs that you want to synchronize into the sync List.
  • Page 29 You can select the synchronal media: NAND Flash or Micro SD/T­Flash card, as following picture shows:...
  • Page 30 Click “Start Sync”...
  • Page 32 The dexter frame will display the synchronized songs. Time: 】button to select: “Adjust”, “Alarm”, “Time Enter the “Time” menu and press【 Zone”. Adjust: Select “Adjust” mode and enter by pressing button. Press 【 】 button to select time (hour, minute, second) and date (year, month,...
  • Page 33 day) that you want to adjust. 】button to adjust time and date, and press Press【 button to confirm. Alarm: Select “Alarm” mode and enter by pressing button, and select “Adjust” to setup the alarm clock time, or select On/Off mode to turn off or turn on the alarm clock, then press button to confirm.
  • Page 34 】buttons to select “Brightness” or “Backlight” menu, and enter Short press【 by pressing button. 】or【 】buttons to setup screen brightness or screen Short press【 backlight time (15 Seconds, 30 Seconds, 1 Minute, Close), and save the setup by pressing button. Record 】buttons to select: Quality, VAD, AGC.
  • Page 35 Select “ No ” or “ Yes ” to decide if you will restore the default setting. Sys Info Select “ Sys Info ” and enter by pressing button, then you can see some system information, like: Firmware version, free flash capacity, and total flash capacity. Refresh: 】button to select “No”...
  • Page 36 】or 【 】buttons to select “FM Tx.“ mode In main menu, short press【 and enter by pressing button. 】 button to select “Setup” or “On/Off”, and press Press【 button to enter. Setup: Select “Setup” mode and short press button to enter, at this time you can adjust the frequency (from 88.1 to 107.9MHz) by pressing 【...
  • Page 37 Note: Please remove the player from the computer when you install USB Disk Win98 driver in Windows98se Operating system. 1. Install USB Disk Win98 driver for computer windows98 Operating system (1) Put CD disk to CD driver (2) Double click the USB Disk Win98 driver to start setup. (3) Select installation language and click “OK”...
  • Page 39 (4) Click “Next>” to enter into next step.
  • Page 40 Close the Driver (X:) window, then click “OK” to finish setup process and restart your computer now, then you can use the player.
  • Page 41 2. Format the player The player is “FAT” format. If you wish to format it, right click removable disk and choose “Format” mode, then click “Start” to format in operating system. As following pictures show: Notice  Please setup the HOLD button in “unlock”...
  • Page 42 Technical Specification Name Description Capacity of Flash Support Micro SD/T­Flash Card, up to 2GB; Memory Build­in Flash Memory, up to 16GB. USB Interface USB2.0 (High Speed) LCD Display 262k TFT Power supply Li­Polymer ≥85dB S/N ratio Audio Frequency Range 20Hz – 20kHz NORMAL, POP, ROCK,CLASSIC, JAZZ, BASS, Custom EQ Support file format...
