Egoman Technology MD398IFOD User Manual

Hide thumbs Also See for MD398IFOD:

Advertisement

Quick Links

Download this manual
0

Advertisement

loading
Need help?

Need help?

Do you have a question about the MD398IFOD and is the answer not in the manual?

Questions and answers

Related Manuals for Egoman Technology MD398IFOD

Summary of Contents for Egoman Technology MD398IFOD

  • Page 3 Note: Please recharge the MP4 player before using it!  Please use your MP4 player properly in case of explosion, fire, electric shock, etc. 1．Do not repair the player by yourself, or it will cause damage. 2．Do avoid getting the MP4 player wet or drop it in water. 3．As U­disk, it will be write­protected if you switch the【HOLD 】button to “Lock”...
  • Page 4 Function features  The player supports MP3 and WMA music file formats. Including WMA files with DRM (Digital Rights Management) function.  Support USB 2.0 capability, much faster than USB 1.1, to enable faster communication with your PC.  The player can record outside voice and FM radio. ...
  • Page 5 Components and button functions Power on/off or Play/Pause Backward/Previous one/Volume down Forward/Next one/Volume MENU button Record/Volume LCD display HOLD button Micro SD/T­flash card slot RESET/Microphone USB port Earphone jack...
  • Page 6 Charging Li –polymer battery safely Connect the PC USB port and the MP3 USB port with the provided USB cable. The power sign is shown dynamic when charging, once full charged, the power sign will stop moving, power is full, please shut off the power. The charging time is approximately 4 hours.
  • Page 7 To change tracks: Short press button. To turn unit off: Press and hold button. NOTE: Please reset your player by pressing the RESET hole while failing to power on or hanging up in power on mode. Please use the Micro SD card correctly in case of happening anything wrong, do not insert or pull out the card while power on.
  • Page 8 Delete MP3 files from the removable USB storage (use the "Delete" command). Remove the player from PC – please follow the steps in case of damaging the player or data loss. Click the left mouse button on the icon that is on the taskbar at the bottom right corner of the desktop.
  • Page 9 CAUTION:  Do not remove the player while files within the USB Mass Storage are being played on your computer.  Do not disconnect the player from your computer while transferring files, or it will cause damage to the player or data loss. Menu Navigation M button: Enter main menu, submenu or return.
  • Page 10 Short press button to confirm. Equalizer Select Equalizer mode and short press button to enter. Short press buttons to select your desired option (e.g. Normal, Pop, Rock, Classic, Jazz, Bass, Custom EQ). Short press button to confirm. Select 3D mode and short press button to enter.
  • Page 11 A­B Select A­B mode and short press button to enter. Short press R/V button to select A point, short press R/V button again to start A­B repeat mode, short press R/V button for the third time to cancel A­B repeat mode. FILE In main menu, short press buttons to select FILE mode.
  • Page 12 Press and hold M button to return to main menu. PHOTO In main menu, short press buttons to select PHOTO mode. Short press button to enter into. Short press buttons to choose your desired photo file Press R/V button to delete the photo file, press buttons to select “No”...
  • Page 13 Short press button to enter into. Short press buttons to choose your desired mode(e.g. USB Mode, Power, Language, Display, Record, Sys Tools, Storage) Short press button to confirm. USB Mode Short press buttons to select USB Mode (MSC mode or MTP mode) DRM 10(optional function) What is DRM? Stands for digital rights management, a technology used to protect digital products...
  • Page 14 NOTE: There are 2 ways to set your MP4 player into MTP mode (1) In “USB Mode” select “MTP mode” mode and short press button to confirm. (2) After connecting the MP4 player with your PC, press【M】button to switch between “...
  • Page 15 Select “Manual” or “Automatic” as your requirement, for example, select ”Manual” and click “Finish”, it will display:...
  • Page 16 Add the songs that you want to synchronize into the sync List.
  • Page 17 You can select the synchronal media: NAND Flash or SD/MMC card, as following picture shows:...
  • Page 18 Click “Start Sync”...
  • Page 20 The dexter frame will display the synchronized songs. Power Short press button to enter your desired option (e.g. Auto off: 002, Always on). Press R/V and buttons to setup the auto off time. Language Short press buttons to select your desired option (e.g. English, CHI (Simp), CHI (Trad), French, German, Italian, Polish, Portuguese, Russian, Spanish).
  • Page 21 Display Short press buttons to select “Brightness” or “Screen” menu, then short press button to enter. Short press buttons to setup screen brightness or screen backlight time. Record Short press buttons to select Quality mode (e.g. High, Normal, Low). Sys Tools Short press buttons to select your desired opinion (e.g.
  • Page 22 Usage steps for conversion: Click “Input Video” column to select the video file you wish to convert for use on the mp3 player. Select the “output frame size”( Advised is 208x176) Select “output frame rate”( Advised is Animated Video) Select “Output Audio Quality”( Advised is Good) MTV video converter allows the user to replace the video clip audio track with an...
  • Page 23 audio file of their own choice. To do this, select the “Input Music” button and choose a music file to replace the original background audio of the input video clip. Click on the “Music Input” check box to enable the function. (Go to 6.
  • Page 24 7. Click “Start Conversion” button to convert video file. Play MTV Video files In main menu, short press button to select “VIDEO“ mode. Short press button to enter into. Short press M button to enter submenu (e.g. Repeat), Short press button to enter Repeat Menu.
  • Page 25 Press and hold M button to return to main menu. Note: the EBOOK function only can browse .TXT files. FM Tx. (Optional function) Select ”FM Tx.” mode and short press button to enter. □ ” column, then press 【 R/V】 button to choose Press buttons to pitch on “...
  • Page 26 USB Driver Installation Note: Please remove MP4 player from the computer when you install USB Disk Win98 driver in Windows98se Operating system. 1. Install USB Disk Win98 driver for computer windows98 Operating system (1) Put CD disk to CD driver (2) Double click the USB Disk Win98 driver to start setup.
  • Page 28 (4) Click “Next>” to enter into next step.
  • Page 29 Close the Driver (G:) window, then click “OK” to finish setup process and restart your computer now, then you can use the player.
  • Page 30 2. Format the MP4 player The MP4 player is “FAT” format. If you wish to format it, right click removable disk and choose “Format” mode, then click “Start” to format in operating system. As following pictures show: Notice  Please setup the HOLD button in “unlock”...
  • Page 31 Technical Specification Name Description Capacity of Flash Support Micro SD/T­Flash Card, up to 2G; Build­ Memory in Flash Memory, up to 4G. USB Interface USB2.0 (High Speed) LCD Display Power supply Li­Polymer ≥85dB S/N ratio Audio Frequency Range 20Hz – 20kHz NORMAL, POP, ROCK,CLASSIC, JAZZ, BASS, Custom EQ Decoding Format...
