Elite ProAV Tab-Tension Pro Series User Manual

Portable tripod tab-tensioned projection screen, matte white and ceiling ambient light rejecting

Advertisement

Tripod Screen Parts Identification

Tripod drape skirt
A.

Tripod Screen Setup

Follow the steps below and Fig. 1 & 2.
1. Place the screen in an upright position (Fig.1) with the
legs toward the ground.
2. Deploy the Tripod Support legs by pushing
down on the Tripod Junction.
3. Turn the tripod's screen case in a 90-degree
horizontal position so that the screen casing is
now parallel to the ground with the screen handle
facing the bottom of the top hook.
4. Completely extend the legs as much as possible
so they are stable and position them away from
objects that may interfere with their balance. DO
NOT stand the tripod on an unstable platform to
avoid an injury should the tripod screen collapse.
11262019JA
Tripod Tab-Tension Pro Series
Portable Tripod Tab-Tensioned Projection Screen
For models: CineWhite UHD-B (matte white) and
CineGrey 5D® (Ceiling Ambient Light Rejecting)
www.eliteproav.com
1
Fig.1
4
USER'S GUIDE
3
2
Fig. 2
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tab-Tension Pro Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Elite ProAV Tab-Tension Pro Series

  • Page 1 Tripod Tab-Tension Pro Series Portable Tripod Tab-Tensioned Projection Screen For models: CineWhite UHD-B (matte white) and CineGrey 5D® (Ceiling Ambient Light Rejecting) USER’S GUIDE Tripod Screen Parts Identification Tripod drape skirt Tripod Screen Setup Follow the steps below and Fig. 1 & 2.
  • Page 2 Do not fold the screen or allow any sharp objects to touch the screen’s surface. • Clean the screen surface often when needed. • Careful use will extend the lifetime of this product For more information, technical support or your local Elite ProAV contact, www.eliteproav.com please visit 11262019JA www.eliteproav.com...
  • Page 3 Notice to Installer: Please use the following installation instructions to obtain superior optical performance from the CineGrey 5D® Angular Reflective CLR®/ALR (Ceiling Ambient Light Rejecting) Screen Make sure to follow these instructions in order for the CineGrey 5D® to perform correctly. 1.

This manual is also suitable for:

Tab-tension pro cinewhite uhd-bTab-tension pro cinegrey 5d
