MARIANNE LAMP TABLE ASSEMBLY INSTRUCTIONS
Thank you for purchasing the Marianne Lamp Table.
Please read the instructions carefully to ensure safe operation of this product.
this sheet prior to assembly to familiarise yourself with the various stages of
PLEASE READ
construction. Carefully open the pack supplied and check the contents against the parts and
fittings check list. Do not destroy any of the packaging until you are certain that you have all
the necessary parts for the assembly.
There are small components used in the construction of this unit.
CAUTION:
These loose items should be kept away from children whilst assembling your unit to avoid the
danger of choking.
If standing the table against a wall, you are advised to use the anti-tilt strap (L) to prevent any
accidents.
Tools Required
49 x 38 x 62 cm (WDH)
Size:
Colour:
Ivory
Batch No. 020517
Page 1 of 10
Number of people
x2
0.5 Hour
Set Up
