1 P r o d u c t d e s c r i p t i o n
8
2 H a r d w a r e c o n f i g u r a t i o n
* Barcode must be used following an update of the embiScan firmware
After an update of the embiScan, it's necessary to scan the Barcode which corresponding to the hardware
used. While the hardware configuration is not done, the embiScan blinks in red with bip.
The hardware used can be known looking at the label located below the product.
If EMSCAN-A-EU scan EMBISCAN_ANTENNA_BOARD_EU_HW06
If EMSCAN-A-CN scan EMBISCAN_ANTENNA_BOARD_CN_HW08
EMBISCAN_ANTENNA_BOARD_EU_HW06
EMBISCAN_ANTENNA_BOARD_CN_HW08
E m b i s p h e r e C o n f i d e n t i a l & P r o p e r t y
1
3
4
6
7
EMBISCAN_MOTHER_BOARD_HW04
# Description
1 Orange LED
2 Red/Green LED
3 Yellow LED
2
RFID single
5 4
mode switch
Barcode
5
Switch
RFID multiple
6
mode switch
7 Blue LED
8 USB connector
Function
RFID activity
indicator light
Red – Error
Green – Read
confirmed
RFID multiple mode
indicator light.
RFID single mode
activation button
To read barcode
RFID multiple mode
activation button
Lights up when the
product is ON
USB cable interface
for computer
connection
