Data Logging - Ecom CN Manual

CN Data Logging allows you to save data snapshots into an on-
board flash memory. The purpose is to allow you to record multiple
data snapshots during a day of testing, and then retrieve the data at a
later time. This allows you to view the data only. If you want to upload
the data to a computer, you will need to send your CN to ECOM for
Bluetooth installation. You may also use an IR printer to print
snapshots on-the-spot. Call 1-877-ECOM-411 if you have any
questions.
How to Save a Data Snapshot
1. Initiate analyzer: Power on -> Go to Combustion Measu. -> Select
Type of Fuel -> Press F4/No for Data Processing -> Wait for the
analyzer to complete self-check -> Press
Menu
2. Go to Data Processing -> Select -> Memory Number
3. Input Memory Number using the numbered keypad and press OK
Note: This assigns a number to your test for retrieval later (valid
numbers 0-4088). Write down or remember this number!
4. Press OK again to confirm Memory Number selection
Note: Display may read "Data Record is Empty!" Press OK
5. Press to return to Main Menu and go to Combustion Measu.
6. Insert probe into sample port -> Wait 2 min for readings to
stabilize -> Press 5/Save to capture snapshot -> An M icon will
appear -> Snapshot has been saved temporarily
7. Press (printer button) and select Store to Memory (you can
also Look At or Print) -> Another M icon will appear -> Snapshot
has been saved permanently to on-board memory

Data Logging

to return to Main
