Summary of Contents for Kamasa-TOOLS K 10640
- Page 1 Cordless K 10640 angle grinder...
-
Page 2: Safety And Precaution
SAFETY AND PRECAUTION Consider the work area environment. Do not expose the tool to rain. Do not use the tool in damp or wet locations – Keep work area clean and well lit. Do not use the tool in the present of flammable liquids or gases. Guard against electric shock. -
Page 3: Product Safety Instructions
PRODUCT SAFETY INSTRUCTIONS Disconnect battery pack from tool or place the main switch in the locked or off position before making any adjustments, changing accessories, or storing the tool. Such preventative safety measures reduce the risk of starting the tool accidentally. In case of cup-wheels, cones or plugs with a threaded hole intended to be mounted on the machine spindle, critical dimensions and other data shall be given in order to prevent the spindle end from touching the bottom of the... - Page 4 IMPORTANT SAFETY INSTRUCTIONS FOR CHARGER & BATTERY PACK Caution: To reduce risk of injury, charge only specific type rechargeable battery packs. Other types of battery packs may burst causing personal injury and damage. Before using charger, read all instructions and cautionary markings on battery packs and chargers.
- Page 5 ADDITIONAL SAFETY RULES FOR CHARGER & BATTERY PACK Do not charge battery pack when temperature is below 10°C (50°F) or above 40°C (104°F). Do not attempt to use a set-up transformer, an engine generator or DC power receptacle. Do not allow anything to cover or clog the charger vents. Always cover the battery pack terminals with the battery pack cover when the battery pack is not used.
-
Page 6: Major Components
Grinding Main switch wheel Switch fixity Handle Wheel cover Battery charger K 10258 PRODUCT SPECIFICATION Model No. K 10640 Voltage 18V DC No load speed 7000 rpm Wheel size 125 mm (5”) Total weight 2.35 kg Charging time 1 hour auto cut off... -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS Installing or removing battery pack (See Fig.1 Fig.2) Always switch off the machine before insertion or removal of the battery pack. To remove the battery pack, push the button on the battery pack and pull the tool unit from the battery pack. - Page 8 LED LIGHT ON THE CHARGER Power On (Green light flashes slowly) Battery low (Red light stays illuminated) Battery charged 80% (Green light flashes rapidly) Battery charged 100% (Green light stays illuminated) Battery pack temperature is too hot or too cold (Red light flashes slowly) Battery pack malfunction (Red and Green lights stay illuminated) Charger shall be plugged into a 100-240V a.c outlet only.
- Page 9 OPERATION INSTRUCTIONS Switch fixity For safety concern, push the switch fixity forward, then press main switch upward to operate the tool. Switch fixity Main switch Lock nut Installing the grinding wheel Release the lock nut by pressing the lock button. (Use key if not able to release by hand) Wheel washer...
- Page 10 Press the lock button after tighten the lock nut. Use the key to tighten the lock nut. Before using the tool, ensure that the lock button is fully released. Lock button Installing the handle Screw hole Install the handle to the front cover screw hole.
-
Page 11: Parts List
PARTS LIST Pos. Stock No. Parts name Pos. Stock No. Parts name Front cover screw K 10644 Trigger lever K 10642 Front cover gearbox ass´y Wire Bush Wire Motor screw Wire Motor fixity K 10646 Discharge protector K10643 Motor Trigger pin Grindstone sheath Battery connector Grindstone gasket... - Page 12 K 10640 www.kamasatools.com...
