- Page 1 ContiPressureCheck ™ Hand-held tool...
- Page 2 Hand-held tool brief instructions....................3 Homologation/Kanada Canada, Industry Canada (IC) Notices “This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, (2) this device must accept any interference, including interference that may cause undesi- red operation of the device.“...
-
Page 3: Tool Overview
General ► These brief instructions are only intended to illustrate the most im- portant operating steps and functions of the hand-held tool and are a supplement to the actual user manual. Make sure you also read the detailed user manual. Tool overview Bezeichnung Task... - Page 4 Charging the hand-held tool ► Before using the tool for the first time, charge the tool for at least 12 hours according to the charging instructions. ► According to the the charging instructions, the tool must be charged for at least 12 hours once a month. ‹...
-
Page 5: Menu Control
Menu control Calling a menu function Use the arrow keys to select the desired menu item. ‹ ‹ Confirm selection with the Return key and call up the menu item. ‹ If the menu includes submenus, use the arrow keys to select the desired menu item and confirm selection with the Return key ‹... -
Page 6: Menu Structure
Menu structure Check sensor Read the data of the tire sensor. Activate Sensor Switch sensor to operating mode. Deactivate Sensor Switch off cyclic transmission (power save mode). Actions on Tire Show Display last received tire sensor data. Check Read the data of the tire sensor. Activate Switch sensor to operating mode. - Page 7 SW Update Update the software of the CCU (control unit). Update the software of the display. Update the software of the switching module. Connection to the PC Communicate with the SD card via a USB cable. Set the desired menu language of the hand-held tool. Available languages: Czech, Danish, German, English, Spanish, Language French, Italian, Hungarian, Dutch, Norwegian, Polish, Portugue-...
-
Page 8: Sd Memory Card
SD memory card Slot for SD memory card The SD memory card is supplied with the hand-held tool by default. ► If no SD memory card is inserted in the hand-held tool, the memory card is either defective or the software was not correctly installed, only "ENGLISH"... -
Page 9: Log Files
Log files The log files that are created when working with the hand-held tool are stored in the "REPORT" directory on the SD memory card (see Directory structure). A unique name is automatically assigned to identify the individual log files. This is made up as follows: File name? Date... - Page 10 Reading an accessible sensor In the event that the sensor is easily accessible, proceed as follows for reading: Hold the hand-held tool with antenna directly in ‹ front of the sensor as illustrated. Fetching a sensor fitted in the tire When fetching the tire sensors, the following is displayed: In the animation, the marker point moves along the side wall in a specified direction...
- Page 11 Disposal This tool may not be disposed of in the domestic refuse. The hand-held tool contains a lithium battery that is cast into the housing and cannot be replaced. After reaching the end of its service life, the tool must be disposed of in accordance with all current local, regional and national laws and regulations.
- Page 12 Continental Reifen Deutschland GmbH Büttnerstraße25 30165 Hanover Germany www.contipressurecheck.com www.continental-truck-tires.com www.continental-corporation.com RF Testing Device Tool-No. 040072...
