MOUNTAIN ASH
GAS FIRE PIT
Model No. GF1003BLK
The ideal solution for extending the season of
outdoor entertaining
Creates a stylish and attractive ambience
Direct ignition
Stainless steel burner for extra long-term reliability
Complete with hose and POL regulator
Efficient and powerful 32 MJ/h output
Adjustable heat output
Operates for approximately 9 hours on a properly
filled 9Kg Propane cylinder
For outdoor use only
Gas certified to Australian standards
EDEN
IMPORTANT: RETAIN THESE INSTRUCTIONS FOR FUTURE USE
FLORENCE
Model No. GF1002CH
FOR YOUR SAFETY
If you smell gas:
1. Shut off the gas to the appliance.
2. Extinguish any open flame.
3. If odour continues, immediately call your gas supplier.
Do not store or use gasoline or other flammable vapour
and liquids in the vicinity of this or any other appliance.
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
Read the instructions thoroughly before installing or
servicing this equipment.
FOR OUTDOOR USE ONLY
PROPANE GAS
03750 02/19
Advertisement
Table of Contents
Related Manuals for Gasmate EDEN
Summary of Contents for Gasmate EDEN
- Page 1 MOUNTAIN ASH GAS FIRE PIT EDEN FLORENCE Model No. GF1003BLK Model No. GF1002CH The ideal solution for extending the season of FOR YOUR SAFETY outdoor entertaining If you smell gas: Creates a stylish and attractive ambience 1. Shut off the gas to the appliance.
-
Page 2: Installation
Installation, Operation and Maintenance Instructions INSTALLATION Proper clearance from combustible materials must Important Safety Rules be maintained at all times. The minimum clearances are as follows: This appliance must only be used in a well Minimum Clearance from Combustibles: ventilated area. Side Rear This appliance shall not be installed or used... - Page 3 The hose must be protected from contact with Any modification to the appliance not described in the hot or sharp surfaces both during use and while installation instructions may compromise the safety of in storage. The hose assembly should be visually this appliance.
-
Page 4: Leak Check
LEAK CHECK Leak Testing WARNING! This must be done before initial use, annually and whenever any components are replaced or serviced. A leak test must be performed annually and each Do not smoke while performing this test, and remove all time a cylinder is hooked up or if a part of the gas sources of ignition. - Page 5 OUTDOOR GAS FIRE PIT ASSEMBLY IMPORTANT: Remove all transit and packaging material from all components before beginning assembly. Dispose of in an environmentally friendly manner. STEP 1 Position the fire pit in the outdoor area you would like to use it. Ensure that this location is OUTDOORS, refer to page 7 for clearances.
- Page 6 STEP 2 This is a 2 person assembly. To assemble the glass surround panels position the 4pcs of bottom aluminium brackets on the top of the fire pit, ensuring that the pin goes into the small hole. Screws should be facing the inside. Make sure you have the top brackets close by before you start assembling the glass in step B and step C.
- Page 7 OUTDOOR GAS FIRE PIT - For Outdoor Use Only Minimum Clearance from Combustible Surfaces*: SIDE CLEARANCE SIDE CLEARANCE 500mm 500mm 800mm 530mm *Combustible materials are considered to be wood, compressed paper, plant fibres, plastic or other materials that are capable of being ignited and burned.
-
Page 8: Troubleshooting
TEST FIRING OUTDOOR GAS FIRE PIT Test fire appliance, following the lighting instructions. Leak test all gas connections with soapy water. Soap bubbles indicate gas leakage. DO NOT use a match to test for gas leaks. WARNING: White smoke may appear around the burner during the first minutes of the initial firing. - Page 9 SAFE APPLIANCE LOCATIONS This appliance shall only be used in an above ground open-air situation with natural ventilation, without stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural convection. Any enclosure in which the appliance is used shall comply with the following: An enclosure with walls on all sides, but at least one permanent opening at ground level and no overhead cover (see Example 1).
- Page 10 For any queries or assistance call Customer Service (Australia Only) 1300 174 876 Hours of operation: Monday to Friday 8am - 5pm EST Do not return to place of purchase. Keep your purchase receipt, this will be required to make any claims under the 12 month warranty.
