Gasmate GM142 Instruction Manual

Cinder gas fire table
Hide thumbs Also See for GM142:

Advertisement

Quick Links

DANGER
If you smell gas:
1. Shut off the gas to
the appliance.
2. Extinguish any open
flame.
3. If odour continues,
keep away from
the appliance and
immediately call
your gas supplier or
fire department.
Retain these instructions for future use.
Important: The installer or seller must leave these instructions with the consumer.
4969-07/18
Cinder Gas Fire Table
Model No. GM142-152
CARBON MONOXIDE HAZARD
WARNING:
Do not store or use gasoline, or other
flammable vapors and liquids, in the
vicinity of this or any other appliance.
An LPG Cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property damage.
Read the installation, operating, and
maintenance instructions thoroughly
before installing or servicing this
equipment.
This appliance can
produce carbon
monoxide which has
no odour.
Using it in an enclosed
space, eg. boat,
caravan, tent, car,
campervan or house,
may cause death.
CARBON MONOXIDE HAZARD
This appliance can produce carbon
monoxide which has no odour.
Using it in an enclosed space, eg. boat,
caravan, tent, car, campervan or
house, may cause death.
CARBON MONOXIDE HAZARD
Never use this appliance in an enclosed
space such as a camper, tent, car or home.
WARNING:
For Outdoor Use Only
CARBON M
This appliance can
produce carbon
monoxide which has
no odor.
Using it in an
enclosed space can
kill you.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GM142 and is the answer not in the manual?

Questions and answers

Summary of Contents for Gasmate GM142

  • Page 1 Cinder Gas Fire Table Model No. GM142-152 CARBON M CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odour. Using it in an enclosed space, eg. boat, caravan, tent, car, campervan or house, may cause death. CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odour.
  • Page 2: Installation

    Installation, Operation and Maintenance Instructions INSTALLATION 3. Proper clearance from combustible materials must be Important Safety Rules: maintained at all times. The minimum clearances are This appliance must only be used in a well ventilated as follows: area. 1. This appliance shall not be installed or used indoors, Minimum Clearance from Combustibles: in buildings, garages or any other enclosed area.
  • Page 3 7. The hose assembly should be properly located out of 5. Reconnect the regulator to the gas cylinder. pathways where people may trip over it. The hose 6. Leak test the connection using a soapy water solution. must be protected from contact with hot or sharp Ensure no bubbles appear before proceeding.
  • Page 4: General Assembly

    GENERAL ASSEMBLY Connecting & Disconnecting to Gas Source 3. When connecting the hose to the cylinder tighten the nut to a positive stop by hand. IMPORTANT: Before connecting and 4. Open cylinder valve fully. If a leak can be heard at disconnecting appliance to gas source, make either end of the hose, turn cylinder off and tighten sure control knob is in ‘OFF’...
  • Page 5: Exploded Diagram

    EXPLODED DIAGRAM Part Name Screen Fire pan Thermocouple Grounding wire Ignition Pin/wire Fire Table Body Door Battery Wing screw Control panel Ignitor Control Knob Hose and regulator Safety valve Metal Hose Nozzle Burner ring...
  • Page 6: Tools Required

    ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS STEP 12 STEP 11 STEP 11 Step 3 Your fire table must be installed on flat, stable surface, Ensure cylinder valve is in its full off position. Check Turn on the gas cylinder ensuring that the control knob Ensure cylinder valve is in its full off position.
  • Page 7 ASSEMBLY INSTRUCTIONS STEP 14a Step 5b: Step 7 quid and If the connection is leaking, bubbles will start to grow STEP 14b STEP 14c Tighten the connections using a crescent then repeat le as Place all lava rocks evenly in the fire table on the top in the soapy solution.
  • Page 8: Lighting Instructions

    TEST FIRING APPLIANCE Test fire appliance, following the lighting instructions 9. In the event that the flame goes out (due to wind found on the appliance. Leak test all gas connections with or other reasons) the flame failure device will soapy water.
  • Page 9: Troubleshooting

    TROUBLE SHOOTING Problem: Condition: Solution suggested: Igniter pin and burner are wet. Wipe dry with a cloth. Igniter battery is incorrectly inserted. Check that battery is correctly inserted. Igniter pin cracked or broken. Contact retailer where purchased for replacement part. Appliance won’t light Reconnect wire to the igniter box...
