ecolight SE1049-BP2-02LF0-E User Manual

LED MOTION-ACTIVATED BATTERY OPERATED SECURITY LIGHT
LUMINAIRE DE SÉCURITÉ À DEL ALIMENTÉ PAR PILE ET ACTIVÉ PAR LE
MOUVEMENT
LUZ DE SEGURIDAD DE LED QUE SE ACTIVA CON EL MOVIMIENTO Y
FUNCIONA A BATERÍA
To Begin/Pour commencer/Para comenzar
WARNING: Please read this entire manual before installation.
Verify the following contents:
AVERTISSEMENT : Veuillez lire ce mode d'emploi du début à la fin avant
de commencer l'installation. Vérifiez le contenu suivant :
ADVERTENCIA: Por favor, lea este manual completo antes de realizar la
instalación. Verifique el siguiente contenido:
Required/Nécessaire/Se necesita
Installation time: 30 minutes / Durée de l'installation: 30 minutes / Tiempo de instalación: 30 minutos
English

Warnings and Cautions

WARNING: LEDs can be damaged by electro static discharge (ESD) shock.
Before installation, discharge yourself by touching a grounded bare metal
surface to remove this hazard.
CAUTION: This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
IMPORTANT: Select the installation location carefully. Do not install in areas
having pedestrian or motorized traffic, pools or bodies of water, or trees/
bushes that move in the wind. All of these may trigger the motion sensor
security light and may be disruptive to the intended operation of the light.
SAVE THESE INSTRUCTIONS.

Assembly Instructions

1
Fig. 1
Fig. 2
housing cover to the mounting surface with wood screws (Fig. 2).
2
Fig. 3
Fig. 4
(Page 4)
(Página 7)
L ow battery
indicator
Batterie faible
indicateur
Indicador de
batería baja
OFF ON OFF ON
Mounting base
Base de fixation
Base de montaje
3/16 in.
4.75mm
Remove the mounting base by turning counter
clockwise until it comes loose. For mounting to
concrete or masonry, install the anchors, by
drilling two 3/16-in. pilot holes into the mounting
surface. Insert the anchors into the holes and
tap them into place so they are flush with the
surface (Fig. 1). Place the rear housing cover,
with the writing facing away from the wall, over
the mounting location and secure the rear
Remove the screw on the battery compartment
cover (Fig. 3). With your fingertip, pull up on the
battery compartment catch and pull outward to
remove the battery compartment cover (Fig. 4).
- 1 -
Hardware kit
(Actual hardware may differ from illustration)
Trousse de quincaillerie
(La quincaillerie incluse peut être différente
de l'illustration)
Kit de aditamentos
(Los aditamentos reales pueden diferir de los
que semuestran en la ilustración.)
(Page 1)
