CPS PRO-SET CC800A Series Quick Manual

Programmable charging scale
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

P
S
CC800A Series
RO-
ET
®
Programmable Charging Scale
CERTIFIED
Calibrated to standards traceable to the
National Institute of Standard and
Technology (NIST).
CC800A

SPECIFICATIONS

Working Load Capacity:
0-220lbs (100kg)
Overload Warning At:
220 lbs (100kg)
Operating Temperature:
14°F to 122°F or -10°C to 50°C
Operating and Storage Humidity:
0 to 95% non-condensing
Display Resolution (oz./ gm. Increments):
.25 ounces (10 grams)
Accuracy:
± 0.05% of reading or ± .25 oz. (10 grams) whichever is greater
Operating Power Source:
Two 9V alkaline battery (ANSI 1604AC-IEC 6LR61)
Battery Life:
30 hours of continuous use
Battery Indicator:
Battery symbol with 3 segment Power Level Bar Graph
Maximum Working Pressure:
500 PSIG (34 bar)
Max. Operating Pressure Differential:
485 PSIG
Weight:
8 lbs 8 oz. (3kg 900g)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO-SET CC800A Series and is the answer not in the manual?

Questions and answers

Related Manuals for CPS PRO-SET CC800A Series

Summary of Contents for CPS PRO-SET CC800A Series

  • Page 1: Specifications

    CC800A Series ® Programmable Charging Scale CERTIFIED Calibrated to standards traceable to the National Institute of Standard and Technology (NIST). CC800A SPECIFICATIONS Working Load Capacity: 0-220lbs (100kg) Overload Warning At: 220 lbs (100kg) Operating Temperature: 14°F to 122°F or -10°C to 50°C Operating and Storage Humidity: 0 to 95% non-condensing Display Resolution (oz./ gm.

  • Page 2: Key Functions

    INTRODUCTION The CC800A is the state of the art battery operated weighing and charging scale. The CC800A has been designed to be accurate, rugged and reliable over a large weighing span (220 lbs/ 100kg). The CC800A can also charge the high-pressure refrigerant R-410A. The CC800A incorporates a hand held unit with 7 keys and an extra large LCD display for easy viewing.

  • Page 3: Operation

    OPERATION The CC800A can be used for Weighing, Charging and Recovering refrigerants. The following are instructions and information on how to use the CC800A for common refrigeration service functions. WEIGH MODE 1) Place the Scale on a level, rigid surface. 2) Press POWER key to turn the unit ON, any weight on platform will be set to zero (Tare).

  • Page 4: Other Features

    RECOVERY Figure 2 1) Place the Scale on a level, rigid surface. 2) Press POWER key to turn the unit ON, it zeroes out any weight on platform. 3) Select the desired unit by pressing UNITS key. 4) Connect scale as shown in Figure 1. Do not place cylinder on platform at this time.
  • Page 5 Krijgsbaan 241, 2070 Zwijndrecht, Belgium Tel: (323) 281 30 40, Fax: (323) 281 65 83 E-mail: info@cpsproducts.be CPS Products Australia PTY. LTD. 109 Welland Avenue, Welland, South Australia 5007 Tel: +61 8 8340 7055, Fax: +61 8 8340 7033 E-mail: sales@cpsaustralia.com.au...
