  • Page 3 Of course, should you ever have any problems or questions, please contact your local SOVEMA dealer or contact us at the addresses or numbers indicated in this manual. SOVEMA manufactures a variety of innovative equipment. If you are interested in discovering our entire range, please contact us.
  • Page 4: Table Of Contents

    21 - STORAGE page 22 - MAINTENANCE page 24 - LIMITED WARRANTY POLICY page 30 - WARRANTY REGISTRATION page 31 - SOVEMA PRODUCT LINE page 34 - DECLARATION OF CONFORMITY page 35 OPERATION & MAINTENANCE MANUAL page 2 Release 2017...
  • Page 5: Symbols

    SYMBOLS These symbols appear throughout the manual. Remember their meaning and advice. CAUTION! YOUR SAFETY IS IN DANGER! READ CAREFULLY USE PROTECTIVE GLOVES OPERATION & MAINTENANCE MANUAL page 3 Release 2017...
  • Page 6: General Information

    GENERAL INFORMATION All implements with moving parts are potentially hazardous. The manufacturer has designed the implement to be used with all the safety equipment properly connected. The purpose of this manual is to assist you in safely maintaining and operating the implement. These instructions have been compiled from our experience.
  • Page 7: Safety Decals

    SAFETY DECALS Safety decals on the implement contain important safety warning messages. To prevent injuries we invite the operator to read them carefully and keep them clean. Check that all the decals are on the machine. If not, DO NOT USE the machine and report to the Dealer immediately to get the decals.
  • Page 8 Danger. Hands and feet can be injured by moving knives. Keep away from the implement. Danger. Your feet can be injured. Keep away from the implement. Danger. Your hands can be injured. Do not remove safety shields and keep away from moving parts. Danger.
  • Page 9: Safety Instructions

    Before using the implement you must be sure to know the main safety precautions; in fact many accidents are caused by not observing these simple rules. Sovema S.r.l. declines to the full extent allowed by the applicable laws all liability and responsibility for any damages of any kind resulting from the breach rules and guidelines expressed in this manual PRE-OPERATIONAL AND OPERATIONAL RULES.
  • Page 10 • Make sure the PTO shaft is firmly connected to the tractor and the implement and that the locking pins have snapped shut. • For connecting and disconnecting the PTO shaft, please refer to the manufacturer’s instruction manual and to your tractor’s instruction manual. •...
  • Page 11 • Before performing maintenance on this machine, drive to a level area, turn off the engine, disengage the PTO, lower the machine, set the brakes and remove the ignition key . • Keep all persons away from the service area while performing maintenance. •...
  • Page 12: Main Checks List

    MAIN CHECKS LIST Before connecting the machine to the tractor, read the following instructions: • Make sure the weight and power of the tractor is suitable to the machine you want to connect. If you have any doubt, please refer to the technical specifications. •...
  • Page 13: Technical Specifications

    TECHNICAL SPECIFICATIONS The implement described in this manual is a flail mower from the FC-2 series. Working Rotor Weight Width -A- Depth -B- Height -C- MOD. Width cm/inches ( rpm ) ( rpm ) Kg./Lbs. cm/inches cm/inches cm/inches 185 / 73"...
  • Page 14: Connecting The Machine

    CONNECTING THE MACHINE The machines described in this manual do apply to any kind of tractor provided of universal three-point hitch. The characteristics (length, diameter of the holes for the lifting pins) of the tractor's lifting arms depend on the type of tractor, therefore it is necessary to prepare the machine in order to properly hitch the implement.
  • Page 15 • Connect the 3rd point of the tractor to the high plates of the implement by using a pin and a cotter key (fig. 1). • Lift the implement and fix the stand support high in its socket with the supplied pin. •...
  • Page 16: Cutting Height Regulation

    CUTTING HEIGHT REGULATION Skid-equipped machines If your implement is equipped with side skids, the height adjustment is made by regulating the height of the skids as per following instructions: (fig. 1): • Loosen screw “a”; • Unscrew screws “b”.; • Adjust the skid as needed, screwing back screws “b”...
  • Page 17 If your mower is equipped with a rear roller, the adjustment is carried out by regulating the two roller support plates as follows (fig. 2): • Loosen screw “c”. • Unscrew screws “d”. • Adjust the roller as needed, screwing back screws “d” in one pair of holes located in the support plate.
  • Page 18 Wheel-equipped machines If your mower is equipped with two rear wheels, the cutting height adjustment is carried out by adjusting the two supports of each wheel. (fig. 3): • Loosen screw “e”.; • Unscrew screw “f”; • Adjust the skid as needed, screwing back screw “f” in one of the holes located in the support itself;...
  • Page 19: Operating The Implement

    OPERATING THE IMPLEMENT After having completed all safety checks and made sure the mower is parallel to the ground, proceed as follows:: • Raise the machine off the ground in order to let the knives start moving without touching ground to avoid damages. •...
  • Page 20 The machine must be used only if equipped with all its components as supplied by the Manufacturer (safety devices included). The implement must not operate without the rear shield or modified as to leave the rear shield open. No other component can be modified. OPERATION &...
  • Page 21: Troubleshooting

    TROUBLESHOOTING During work several problems can happen. UNUSUAL NOISES. During operations, if the implement produces loud, unusual noises, the operator must immediately stop it and follow these instructions:: • Make sure there are no broken mechanical parts. • Verify that the gearbox contains the correct amount of oil. If the oil level is too low (please see the chapter on maintenance), the gears of the conic couple are not adequately lubricated and will overheat the remaining oil if operations continue.
  • Page 22 CUTTING ANOMALIES. If after the operations the mower failed to obtain a clean, even cut, the operator must follow these instructions: • Check knives conditions. The knives can be worn and less effective. Please replace them. • Check if the cutting height has been properly set up. The regulation of the implement may be uneven.
  • Page 23: Disconnecting The Machine

    DISCONNECTING THE MACHINE The disconnection of the implement from the tractor must be carried out on a flat surface. It’s a dangerous operation. Please read the following instruction carefully. • While remaining in the tractor seat, put the tractor PTO in neutral. •...
  • Page 24: Storage

    STORAGE The machine represents an investment for the operator. If left unused for a long time, we suggest to follow these simple rules: • Wash and dry the machine; • Check all moving parts. In case of excessive wear replace the parts or contact your local dealer;...
  • Page 25 FIRST USE OR USE AFTER A LONG PERIOD OF INACTIVITY. Before using the implement for the first time or after a long period of inactivity, follow these steps: • Make sure the machine is not damaged; • Verify all mechanical parts They must be in good state and they must not present signs of rust;...
  • Page 26: Maintenance

    MAINTENANCE The efficiency and lifetime of this machine strongly depend on the observance of its maintenance schedule. The schedule reported below is subject to change since it refers to a normal usage and does not take into consideration heavier working conditions which require a more frequent maintenance.
  • Page 27 EVERY 20 WORKING HOURS • Check belt tension by measuring belt tightness. Correct tightness results when belt deflection along the front side of the belt is 1 cm, as a result of the pressure applied with the index finger to the centre of the belt length (see fig. 1). MAX 10 mm FIG.
  • Page 28 LEFT SIDE PANEL TUBE SEMI-AXLE SUPPORT PLATE OPERATION & MAINTENANCE MANUAL page 26 Release 2017...
  • Page 29 Remember to tighten the belts correctly. A high number of worn belts in a short time is not normal. Please check that the rotor rotates freely without obstacles blocking its movement. • Make sure the knives are still sharp and that they do not show signs of breakages or excessive wear.
  • Page 30 FIRST 100 WORKING HOURS • When the machine has done its first 100 hours, change the oil from the gearbox. To proceed, remove the plug located under the box, drain all the oil through the discharg- ing hole, then fill in with new oil through the filler hole. This substitution is necessary because the gears are new and so are subject to quicker worn.
  • Page 31 TOXICOLOGICAL INFORMATION ABOUT LUBRICANTS. PROTECTIVE TYPE OF DANGER FIRST CARE EQUIPMENT Possible rash after Wash thoroughly with SKIN Safety gloves or lotion prolonged exposure soap and water Possible irritation on EYES Protective glasses Rinse with running water contact Maintain an oil mist level Expose to fresh air and Possible irritation after INHALATION...
  • Page 32: Limited Warranty Policy

    The judgement of SOVEMA S.r.l. in all cases of claims under this warranty shall be final and conclusive and the original purchaser agrees to accept its decisions about all questions as to defects and/or to the exchange of any part or parts.
  • Page 33: Warranty Registration

    • The machine was tested and operates correctly. (Address) (Address) ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ Date: Signature: Date: Signature: DELIVER TO SOVEMA S.R.L. OPERATION & MAINTENANCE MANUAL page 31 Release 2017...
  • Page 34 OPERATION & MAINTENANCE MANUAL page 32 Release 2017...
  • Page 35 Sovema S.r.l. Via Olmo 6/10 41013 Gaggio In Piano (MO) ITALY Tel: 0039 (0)59 93 85 85 Fax: 0039 (0)59 93 85 12 e-mail: sovema@sovema.com www.sovema.com WARRANTY REGISTRATION This warranty will become valid only if this form is completed and signed by both the Purchaser and the Deal- er and is returned within 8 days of purchase date! IF NOT WARRANTY IS INVALID.
  • Page 36: Sovema Product Line

    SOVEMA PRODUCT LINE HIFT OTARY ILLERS • 15 different models • for tractors from 12 to 70 HP • working width from 80 to 200 cm. IXED OTARY ILLERS • More than 45 different models • for tractors from 15 to 130 HP •...
  • Page 37 LAIL OWERS HREDDERS • more than 50 different models • for tractors from 15 to 100 HP • working width from 100 to 290 cm. LAIL OWERS OLLECTORS • 6 different models • for tractors from 30 to 60 HP •...
  • Page 38 OTARY AKES • 3 different models • for tractors from 30 to 50 HP • working width from 340 to 450 cm. EDDERS • 6 different models • for tractors from 10 to 40 HP • working width from 250 to 750 cm. ICKLE OWERS •...
  • Page 39: Declaration Of Conformity

    : 059-938512 E-MAIL : sovema@sovema.com WEB site : http://www.sovema.com DECLARATION OF CONFORMITY CE The undersigned company, Sovema S.r.l., Via Olmo 6, 41013 Gaggio di Piano (MO) Italia Hereby declares the machine Model :……………………………………………… Serial Nr : ……………………………………………… Year : …………...
