9. Use the ControlSpace Designer™ software to verify the card was inserted
®
correctly:
a) Press scan and confirm that the software detects the card.
b) If the card was installed correctly, right-clicking the ESP and displaying
its properties will show ESPLink in the correct slot in the ESP.
See Figure 3.
Figure 3
10. If an error message appears, or the software does not properly detect the
ESPLink Output Card, repeat the installation instructions. Be sure that the
card is completely pushed into the connector, and that the card is properly
aligned in the chassis.
