MODEL SW3240 / SW3250 USER GUIDE
Pinnacle Full Height and Tabletop Lectern with
Internal 16 Channel UHF Wireless Receiver and
SW3240
Thank you for choosing the SW3240 / SW3250 Pinnacle
Lectern from AmpliVox Portable Sound Systems.
We are excited in introducing this truly unique system. Our
system combines flexibility with functionality. Please refer to
this user guide as you enjoy the unique capabilities of another
quality product from AmpliVox Portable Sound Systems.
We encourage you to visit our website www.ampli.com to
register your product for its warranty coverage, sign up to
receive our newsletter, download our catalog, and learn more
about the complete line of AmpliVox audio visual products,
including portable PA systems, and lecterns.
The SW3240 / SW3250 Pinnacle Lecterns come with a Gooseneck Mic. that installs in the cable mounted in the
shock mount on the reading table. That cable is prewired to the XLR connector at the lower side of the unit where
you plug in an XLR cable to the house PA system.
The LED Lamp is powered by an AC power adapter that is plugged into an outlet strip mounted inside the unit which
has its plug mounted to the bottom side of the unit. You plug in the supplied power cord from the base of the unit to
the house AC.
The clock/timer is battery operated (LR44 Watch Batteries, not included). The batteries can be replaced by pulling the
clock out of the panel. The batteries are in the back of the timer.
SW3250
INCLUDES:
Built-in Flush Mount Amplifier w/Internal 16 Channel
•
UHF Wireless Receiver
Electret Gooseneck Microphone
•
Wireless headset and lapel mic with transmitter
•
25 Foot XLR Cable
•
16 Foot Power Cord
•
Amplifier
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AmpliVox SW3250
Summary of Contents for AmpliVox SW3250
- Page 1 PA systems, and lecterns. The SW3240 / SW3250 Pinnacle Lecterns come with a Gooseneck Mic. that installs in the cable mounted in the shock mount on the reading table. That cable is prewired to the XLR connector at the lower side of the unit where you plug in an XLR cable to the house PA system.
- Page 2 Equipment damage, safety hazard or fire could result. Remove batteries if the unit is not going to be used for long periods of time to prevent leakage. SW3240 / SW3250: Both lecterns run on AC power or battery power. The battery carriage holds 10 D-cell alkaline batteries or Amplivox optional S1465 NiCad Battery Pack (Fig.1) which also requires a S1460 AC adapter for recharging.
- Page 3 Also, audio signals from any device connected to the "AUXILIARY" input will be heard through the house system, such as the audio portion of a computer presentation, CD player or MP3 device for example. The XLR output may also be modified to deliver a line-level output if needed. Contact Amplivox Customer Service for further details. GOOSENECK CONDENSER MICROPHONE The electret condenser microphone is designed for extra sensitivity to easily pick up the presenter's voice.
- Page 4 RA#, the defective unit is to be returned to AmpliVox in either its original packaging or packaging affording an equal degree of protection. You will bear the cost of shipping the product to AmpliVox. If the product is covered by the warranty, AmpliVox will bear the cost of shipping product back to you after the completion of service under this warranty.
