prime3 ABT02 Owner's Manual

Owner's manual
Model: PRIME3 UP! (ABT02), Bluetooth speaker
· Use in accordance with the instruction manual.
· Do not install the device near any heat sources such as radiators,
heat registers, stoves or other apparatus (including amplifiers) that
generate heat.
· Clean only with a dry cloth.
· Do not cover or obstruct ventilation holes on speakers' grill.
· Do not expose the device to dripping or splashing.
· Use only original accessories specified by manufacturer.
When this crossed-out wheeled bin symbol is attached to a product it means that the product is covered by the European
Directive 2012/19/EU. Please inform yourself about the local separate collection system for electrical and electronic
products. Used appliance should be delivered to the dedicated collecting points due to hazardous components, which may
affect the environment. Do not dispose this appliance In the common waste bin.
Your product contains batteries covered by the European Directive
2006/66/EG, which cannot be disposed with normal household
waste. Please inform yourself about the local rules on separate
collection of batteries because correct disposal helps to prevent
negative consequences for the environmental and human health.
Many thanks for buying our product. This model includes
below main features.
1. Bluetooth function for audio streaming playback.
2. Aux in.
3. Built-in rechargeable battery power.
List of controls：
1. Power buton
2. MicroUSB DC 5V power jack
3. Charging LED indicator.
4. AUX IN jack.
Battery charging
This unit had built-in rechargeable lithium battery inside. Before
start the playing, please follow up below step for charging.
1. Using the supplied USB to microUSB type charging cable
connects the speaker with your USB charger (USB adaptor or USB
output port like on PC, USB rating output: 5V/500mA, other USB
charger with current equal or above 500mA). The microUSB
connector should connect with the DC 5V power jack on the rear
panel of speaker, and another terminal connect with USB charger.
Then plug your USB charger into the household AC power.
2. The charging LED will light on in red colour during charging, and
the red colour LED will off when the battery is fully charged.
3. The speaker will off automatically when the battery power
exhausted, please arrange recharge for playing.
Important: We recommend connect the USB charger with rating
output spec at DC 5V/500mA, or equal or above 500mA output
Hereby, 2N-Everpol Sp. z o.o., declares that this equipment is in compliance with the essential requirement and
other relevant provisions of Directive 2014/53/EU. Declaration of conformity can be obtained from the
product page at www.prime3.eu. Responsible party: 2N-Everpol Sp.z o.o., Puławska 403A, 02-801 Warsaw,
Poland, Phone: +48 22 331 99 59, E-mail: info@prime3.eu
Recording and playback of material might require consent. See Copyright Act 1956 and The Performer's
Protection Acts 1958 to 1972.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of
such marks by us is under license. Other trademarks and trade names are those of their respective owners.
· This product is not a toy, can be used by children only under
supervision of adults.
· Do not expose the device to excessive heat such as sunshine, fire
or the like.
· Do not use during lighting storms.
· Do not expose the device to electromagnetic radiation.
· In order to prevent hearing loss, do not listen to music for
prolonged periods of time.
· Remember to do not use electronic devices in distance smaller
than 10cm from pacemaker.
current USB power. The general USB output on PC (personal
computer) is 5V/500mA (please reference your PC spec for
checking). There may have some charging noise or abnormal
function from speaker if the charging current is too low. If it
happened, please remove the charging power and put the speaker
in a while, then the speaker will reset the function in normal. Please
kindly note this is not malfunction.
Notes:
Your battery lifetime will last longer if you follow up below simple
guidelines for charging and storing.
a. For charging first time, charge it at least 10 hours.
b. Recharge and store the unit within the temperature range of
5°C~35°C (40°F~95°F).
c. Do not charge longer than 24 hours. Excessive charging or
discharging may shorten the battery's life.
d. Battery life naturally shortens slowly over time.
e. Please turn off the speaker if long time not to use.
f. he speaker can play music during charging.
g. Due to prolong charging and discharging, the unit battery life
will be affected and playback time will also be shortened. We
cannot guarantee the same playback consistently throughout and
this is not include in our warranty and service.
Bluetooth operation
The speaker includes Bluetooth function which allows you to
wireless playback the audio with other Bluetooth device like smart
phone etc. Please follow up below for the operation.
2 3 4 1
Your products is designed a
manufactured with high quality
materials and components, which can
be recycled and reused.
