- Page 1 User Manual User Manual Electric Griddles Intertek Models: EG16N, EG24N, EG30N, EG36N 05/2019 Please read and keep these instructions. Indoor use only. www.AvantcoEquipment.com...
-
Page 2: Specifications
All units come with a 6 ft. commercial cord except EG36N which must be hard wired Model Voltage Power Dimensions (LxWxH) Temp. Range Net Wt. Shipping Wt. Plug Type EG16N 120V AC 1750W 16" x 19.75" x 9.5" 120°F - 570°F 52 lbs. 62 lbs. NEMA 5-15P EG24N... - Page 3 User Manual Transportation And Maintenance During transportation, the machine should be handled with care. Cleaning Unplug the unit and allow it to cool before cleaning.Do not use abrasive cleaners or scouring pads. If soap or chemical cleaners are used, be sure they are completely rinsed away with clear water immediately after cleaning. Chemical residue could damage or corrode the surfaces of the unit.
- Page 4 User Manual Exploded Parts Diagram www.AvantcoEquipment.com...
- Page 5 Power Cord 177COPCORD (EG16N), 177COPCORD2 (EG24N & EG30N) Power Cord Clip Body Terminal 177EGTERMNL1 (EG16N), 177EGTERMNL2 (EG24N, EG30N, EG36N) Heating Element 177EGELEM16 ( EG16N), 177EGELEM24 (EG24N), 177EGELEM30 (EG30N), 177EGELEM36 (EG36N) Insulation Heating Element Holder Insulation Board Bottom Plate Foot 177EGLEG...
- Page 6 User Manual Circuit Diagrams EG16N EG24N www.AvantcoEquipment.com...
- Page 7 User Manual EG30N EG36N www.AvantcoEquipment.com...
- Page 8 Equipment Limited Warranty Avantco warrants its equipment to be free from defects in material and workmanship for a period of 1 year. This is the sole and exclusive warranty made by Avantco covering your Avantco brand equipment. A claim under this warranty must be made within 1 year from the date of purchase of the equipment.
