Placing The Harmony Cushion On Your Wheelchair; Adjusting The Air Floatation Cushion Overlay - ROHO HARMONY Operation Manual

Placing the HARMONY Cushion on Your Wheelchair

Place the HARMONY Cushion on your wheelchair
so that the contoured foam area is in the front
portion of the wheelchair seat. The AIR
FLOATATION cushion overlay sits in the upper por-
tion of the cover. The cushion should be placed on
the seat so that the cushion overlay cells are facing
upward.
The cover should be on the cushion so that the zipper area is in the
back portion of the wheelchair seat and the side logo is in the front
left corner. The non-skid material is on the bottom of the cover.

Adjusting the AIR FLOATATION Cushion Overlay

IMPORTANT! Do Not Skip This Section.
Step 1: Open air valve by
twisting it counter-clockwise.
(Air valve is located behind
flap on the left side of the
cushion, toward the front.)
Step 3: Remove the pump
hose from the valve and close
the valve by twisting it clock-
wise.
Step 2: Attach the rubber
hose on the ROHO Pump to
the end of the valve. Inflate
the cushion overlay with the
pump until the cushion
begins to arch.
Step 4: Sit on the
HARMONY Cushion in your
normal sitting position with
armrests and footrests
properly adjusted.
5
