RTS 4010 User Manual

Central electronics
Hide thumbs Also See for 4010:
Table of Contents

Advertisement

Quick Links

Includes:
Model 4001
Model 4001M
Model 4002
Model 4002M
Model 4003
Model 4003M
Model 4020
9300259400 Rev J
Model 4010
Central Electronics
User Manual
Control Station for 4IFB, 1 SA
Control Station for 4IFB, 1SA with Microphone
Control Station for 8 IFB, 2SA
Control Station for 8 IFB, 2SA with Microphone
Control Station for 12 IFB, 3SA
Control Station for 12 IFB, 3SA with Microphone
Portable User Station / Talent Electronics
07/2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RTS 4010

Summary of Contents for RTS 4010

  • Page 1 Model 4010 Central Electronics User Manual Includes: Model 4001 Control Station for 4IFB, 1 SA Model 4001M Control Station for 4IFB, 1SA with Microphone Model 4002 Control Station for 8 IFB, 2SA Model 4002M Control Station for 8 IFB, 2SA with Microphone...
  • Page 2 ROPRIETARY OTICE HIPPING TO THE ANUFACTURER The product information and design disclosed herein were origi- All shipments of product should be made via UPS Ground, prepaid nated by and are the property of Bosch Security Systems, Inc. (you may request from Factory Service a different shipment Bosch reserves all patent, proprietary design, manufacturing, repro- method).

  • Page 3: Important Safety Instructions

    Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

  • Page 5: Table Of Contents

    IFB ....................................9 OPERATION .............................. 19 Operating Instructions ............................19 Setup and Operation of the Central Electronics, Model 4010 ................19 Control Station Operation, Models 4001, 4001M, 4002, 4002M, 4003, 4003M ............20 User Station Operation, Model 4020 ........................20 Substituting TW Intercom Stations for IFB User Stations ..................20 Operating with Telco Dry Pair(s) ...........................20...
  • Page 7 FIGURE 3. A Configuration– 2 System .........................10 FIGURE 4. A Configuration – 3 System ........................11 FIGURE 5. User Station Connection to the 4010 ....................12 FIGURE 6. Program Input and SA Output Connections ..................13 FIGURE 7. Balanced Mic Level Input ........................13 FIGURE 8.

  • Page 9: Introduction And Specification

    CHAPTER 1 Introduction and Specification Introduction The IFB System is a one-way IFB (Interruptible Feedback) communications system (a program interrupt system) created especially to meet the critical requirements of the television broadcast industry, as well as other live or recorded media applications.

  • Page 10: Central Electronics - Model 4010

    Inside the Model 4010, a single large circuit board is used to mount all electronic components. A rear panel terminal strip provides connections for the program inputs, IFB outputs, SA output, and relay contacts. Connection between the Control Stations and the Central Electronics is made through a 50-pin micro-ribbon connector.

  • Page 11: Splitter Assembly - Models 4022 And 4025A

    Splitter Assembly – Models 4022 and 4025A The splitter assemblies connect the control stations with the central electronics via 25-pair cable with micro-ribbon connectors. The Model 4022 features a single male connector paralleling two (2) female connectors to connect two (2) controls/stations to the central electronics.

  • Page 12: Specifications

    Specifications Gain Model 4010 Central Electronics 54dB to 14dB Frequency Response Nominal Output Level 30Hz to 16kHz, +1,-2dB -10dBu, balanced, Z=300 Ohms Noise Size And Weight Interrupt Channel, <-75dBu 4001/4001M Non-Interrupt Channel, <-83dBu 1.72”H x 8.5”W x 3.4”D Total Harmonic Distortion 2.1lbs/2.7lbs...

  • Page 13: Installation

    Standard Installation The Central Electronics, Model 4010, is a rack mounted unit. The rear of the Model 4010 must be supported with the brackets provided. Installation dimensions and outline drawings for all components of the Series 4000 IFB System are located in the Service Manual.

  • Page 14: Connection To Existing Microphones, Tw Type User Stations And Other Sources

    Control Station’s switchboard, the priority of that Control Station can be changed. See Figure 11 through Figure 13. If desired, the priority may be defeated by removing U6 and U16 in the Model 4010 Central Electronics. In this mode all Control Stations have equal priority.

  • Page 15: Expanding The Control Stations All Function

    D100, D105, D110 Mono IFB When the switches inside the 4010 Central Electronics are switched to the right, both left and right channels at the user station will receive the interrupted program feed. See Figure 16. Power Connection to Series 4000 Control Stations...
  • Page 16 A Typical Configuration FIGURE 2. The system may be expanded for up to 12 User Stations, three (3) Central Electronics, three (3) Splitter Assemblies, and four (4) Control Stations. A Configuration– 2 System FIGURE 3.
  • Page 17 A Configuration – 3 System FIGURE 4.
  • Page 18 User Station Connection to the 4010 FIGURE 5.
  • Page 19 Program Input and SA Output Connections FIGURE 6. Balanced Mic Level Input FIGURE 7.
  • Page 20 Unbalanced Mic Level Input FIGURE 8. Line Level Input FIGURE 9.
  • Page 21 Control Station Cable Assembly FIGURE 10. Priority Connections to 4001 Control Station FIGURE 11.
  • Page 22 Priority Connections for 4002 Control Station FIGURE 12. Priority Connections for 4003 Control Station FIGURE 13.
  • Page 23 Speaker Muting Zones FIGURE 14. Return IFB Connections FIGURE 15.
  • Page 24 Stereo-Mono IFB Selection FIGURE 16.

  • Page 25: Operation

    The basics for Model 4020 setup are discussed throughout this chapter. Setup and Operation of the Central Electronics, Model 4010 After you have made all connections, do the following: Plug a stereo headset into the test jack on the front panel of the input 1.

  • Page 26: Control Station Operation, Models 4001, 4001M, 4002, 4002M, 4003, 4003M

    Substituting TW Intercom Stations for IFB User Stations Any RTS TW intercom station may be substituted for a 4020 User Station. The BP-501 User Stations provide stereo IFB. Any other User Stations should have the channel-select a switch set to channel 1to receive the interrupted monaural audio. A TW User Station with the LP (Local Power) option can be used to operate on a dry pair IFB feed providing long distance operation up to 8 kilometers (5 miles) with stepup and stepdown transformers.

  • Page 27: Operating Distances

    Operating Distances With a telco pair, maximum operating distance averages 800 meters (1/2 mile). Doubling up the conductors in a telephone quad extends the operating range to 1600 meters (1 mile). Utilizing an extra power supply and transformers, the range can be extended to 8 kilometers (5 miles) on telco dry pair.
