Ursalink UC11-N1 Quick Start Manual
Hide thumbs
Also See for UC11-N1:
- Quick start manual (12 pages) ,
- Quick start manual (12 pages) ,
- Manual (36 pages)
Table of Contents
Advertisement
Advertisement
Table of Contents
Related Manuals for Ursalink UC11-N1
Summary of Contents for Ursalink UC11-N1
-
Page 1: Quick Start Guide
UC11-N1 Quick Start Guide Ursalink Technology Co., Ltd. -
Page 2: Related Documents
Thank you for choosing Ursalink UC11-N1. This guide will teach you how to install the UC11-N1 and how to connect to Ursalink Cloud. Once you complete the installation, refer to the Ursalink UC11-N1 User Guide on how to perform configurations on the device. -
Page 3: Hardware Introduction
Ursalink UC11-N1 Quick Start Guide 1. Packing List Before you begin to install the UC11-N1, please check the package contents to verify that you have received the items below. 1 × UC11-N1 Device 2 × Data Cable 1 × USB Cable 1 ×... -
Page 4: Dimensions (Mm)
Ursalink UC11-N1 Quick Start Guide 2.2 Dimensions(mm) 2.3 Pinouts Interface 1 Definition 5V/9V/12V 3.3V GPIO1 GPIO2 Switchable Interfaces Reserved RS232 RS485 Interface 2 Definition 5V/9V/12V 3.3V AIN1 AIN2 Reserved USB&Power Connector Definition USB_D+ USB_D- VCC(5-24V) www.ursalink.com... -
Page 5: Hardware Switch
Power off: Beep for 6 seconds 3.2 Hardware Switch When using the analog input and power output of UC11-N1, you can switch the working mode of hardware interface. Please follow the steps: A. Remove the screw caps and take off the roof cover. -
Page 6: Usb Configuration
Ursalink UC11-N1 Quick Start Guide 3.3 USB Configuration Connect UC11-N1 to laptop via USB cable. 3.4 Mount the UC11-N1 Wall Mounting Make sure you have wall mounting bracket, bracket mounting screws, wall plugs, wall mounting screws and other required tools. -
Page 7: Pole Mounting
Ursalink UC11-N1 Quick Start Guide Pole Mounting Make sure you have wall mounting bracket, bracket mounting screws, hose clamp and other required tools. A. Mount the enclosure to the mounting bracket with the bracket mounting screws. B. Loosen the hose clamp by turning the locking mechanism counter-clockwise. - Page 8 Ursalink UC11-N1 Quick Start Guide 4. Connect N1 to Ursalink Cloud This chapter takes example of how to reazlie remote monitoring of sensor data among UC11-N1, Ursalink Cloud and sensor with RS485 serial port. 4.1 Configure UC11-N1 via Toolbox A. Connect PC and UC11-N1 directly via USB port as shown in Section 3.3.
- Page 9 Ursalink UC11-N1 Quick Start Guide E. Click “General->Serial” to configure RS485 property and Modbus channels. 4.2 RS485 Configuration Example UC11-N1 collects data from two Modbus RTU sensors and provides power to them. Sensor property: Sensor Serial Port Slave ID Address...
- Page 10 Ursalink UC11-N1 Quick Start Guide C. Configure Modbus Channels according to information of sensors. After saving configuration, click “Fetch” to check if N1 read correct values. www.ursalink.com...
- Page 11 Ursalink UC11-N1 Quick Start Guide 4.3 Ursalink Gateway Configuration A. Go to “Maintenance->Ping” and use ping tool to check gateway Internet connection. B. Enable “Ursalink” type network server and “Ursalink Cloud” mode. www.ursalink.com...
- Page 12 Ursalink UC11-N1 Quick Start Guide 4.4 Ursalink Cloud Configuration A. Register and log in Ursalink Cloud. Ursalink Cloud URL: https://cloud.ursalink.com/login.html B. Go to “My Devices->Gateway” and click “Add” to add gateway to Ursalink Cloud via SN. www.ursalink.com...
- Page 13 Ursalink UC11-N1 Quick Start Guide C. Go to “Device->My Devices” and click “Add Device”. Fill in the SN of UC11-N1 and select associated gateway. D. Click after UC11-N1 is connected and enter “Interface Settings” to choose and edit relevant data to be shown on dashboard.
- Page 14 Ursalink UC11-N1 Quick Start Guide Note: For more details, please refer to the UC11-N1 user guide. [END] www.ursalink.com...
