- Page 1 1.031 Access Control Panel U-Prox IP100 Installation and programming manual...
- Page 2 About this document his manual covers installation, adjustment and utilization of U-Prox IP100 (hereinafter panel) access control panel. Read this manual carefully prior to installing the system. Characteristics, Intended use and parameters of the panel are described in the section "Summary".
-
Page 3: Table Of Contents
Contents Brief description of the panel ......................4 Intended use ..........................4 Characteristics ........................... 5 Terms ............................6 Description and operation ......................8 Panel ............................8 Terminals ..........................9 Sound and light panel ......................9 Panel operation ........................10 “Normal”... -
Page 4: Brief Description Of The Panel
Brief description of the panel U-Prox IP100 control panel - a device designed to control access to residential and business premises, for pass time and events logging and analysis, including personnel time attendance. The defalt modification panel has built-in proximity card reader (ASK and FSK RF IDs) and keyboard. -
Page 5: Characteristics
Current consumption from 12V power source (off load), max 160 mA Amplitude ripple of DC power supply, no more than 500 mV External reader may be connected to the U-Prox IP100 . It should be U-Prox series Two End-of-line supervised inputs ... -
Page 6: Terms
The information on the identifiers is read with READERS, connected to the ACS control panel. There are several types of RF IDs and readers for them. It is essential that reader and control panel use the same interface. Only U-Prox series readers may be connected to the U-Prox IP 100 control panel. - Page 7 For these purposes the magnetic door sensor, the turnstile rotor position sensor and the position sensor of boom barrier are connected to the input of panel. The input used to connect the sensors, is called the input of the door contact.
-
Page 8: Description And Operation
Description and operation Panel The look of the access control panel is shown in Fig. 1 and 2. Panel enclosure Keypad Fig. 1. U-Prox IP100 panel The top cover of the panel Contol panel electronics, injected with... -
Page 9: Terminals
Terminals Colour / № Name Function 9-wire cable +12 V Connection to the power supply, connection of an external reader Black Connection to the power supply, connection of an external reader, common for input loops Yellow Terminals for Loop... -
Page 10: Panel Operation
Panel operation The panels supplied unloaded with factory settings below in document. In this state, the indicators of readers and the yellow LED on the panel flashes once per second. To make the panel work in access control system (ACS) you have to upload a network setting using the "Configurator"... -
Page 11: Alarm" Mode
attempt to re-pass when "Antipassback" is on (for 1 second buzzer is on and LED is red) entered RF ID is marked as lost or Blocking (for 1 second buzzer is on and LED is red) ... -
Page 12: Blocking" Mode
"Blocking" Mode If it is necessary to deny access to AP to all users of the system, the panel switches into “Blocking" mode. If AP is in “Blocking" mode, the passage is granted only to owners of RF IDs with the sign "Security Service". AP cannot be opened by pressing RTE. -
Page 13: Variants Of Use And Modes Of Output
Panel communicator operates in the notification mode. If there is event (passage, violation of input) event report message is send ACS server. U-Prox IP100 panel can be connected to a computer network via wired connection (Ethernet) or via wireless network. This ensures work within local network (see Figure 3) or via the Internet (see Fig. - Page 14 Fig. 5. An example of a distributed network For setting common network of central office and branches for extra protection using VPN technology is recommend. To provide backup communication channels use routers with two dissimilar channels of access to the Internet.
- Page 15 Update of IP status of address (announcement and extension of reserved IP, if DHCP) Determine accessibility of ACS server and U-Prox IC A control panel (IP or DNS name) Periodic sending of test signals If there is, sending of events. Waiting for server commands.
- Page 16 IP, if DHCP) Determine possibility of accessing the Internet (access to given IP addresses of routers) Determine accessibility of ACS server and U-Prox IC A control panel (IP or DNS name) Periodic sending of test signals If there is, send the events. Waiting for server commands.
-
Page 17: Global Antipassback
U-Prox IP100 control panel can operate in a system of global antipassback. The main controller U-Prox IC A tracks the location of a person on the fact of its passage through the access point. U-Prox IC A receives data about the passages from control panels U-Prox IP400, NDC F18 IP, U-Prox IP100, U-Prox IP300. - Page 18 The location "unspecified" is assigned when registering a new employee, or after the system operator command "location reset" of person is fixed by U-Prox IC A. With the use of global antipassback it is possible to suppress passback, using duplicate card for infiltration (sudden appearance inside), transferring the ID to another person, etc (See Figure 9).
- Page 19 (See Figure 10). Fig 10. Merging access zones U-Prox IP400, U-Prox IP100, U-Prox IP300, NDC F18 IP access control panels can be configured to two variants of behavior in case communication lost with U-Prox IC ...
-
Page 20: How To Work With The Device
How to work with the device The panel is delivered in a small plastic case with subsequent sealing Overall dimensions are shown in Fig. 11. Connection procedure Before installation do initial setup of panel (that specifies settings network parameters) with utility "Configurator"... -
Page 21: Installation Recommendations
Installation recommendations Panel should be installed on the wall next to the door for users may easily pass card to it. To connect the cable under the body of panel it is necessary to have a small deepening or a hole with diameter of 14 mm. -
Page 22: Connecting An External Reader
Connecting an external reader The panel has a port for external readers. Only U-Prox series reader may be used with panel as external. The connection of U-Prox Mini RF ID reader is depicted on Fig.14. Fig 14. Connecting an external reader Color matching circuits: ... -
Page 23: Request To Exit Button (Rte)
For example, to open the door manually, by the secretary or security guard. Panel U-Prox IP100 has built-in RTE button, which can be activated or deactivated during programming. The number of the loop of this button - № 3. -
Page 24: Combined Loop- Rte And Door Contact
(220V and battery). In Fig. 18 connection of power supply and panel U-Prox IP100 is shown. PWG and ACG can be open collector outputs or relay outputs (dry contacts) sink to the ground at normal mains power and battery state respectively. -
Page 25: Actuators
Actuators Panel has one relay to supervise actuators. Using this output, panel controls electric lock or latch, operation of the barrier, turnstile, or turns on any optional hardware. Relay 1 has normally closed and normally open contacts. The relay contacts rating is 1A @ 24 V. -
Page 26: Connection
Connection Wired or wireless computer network used for U-Prox IP100 communication to the ACS server. Device setup is possible with using autoconfiguration or manually with a PC using the software "Configurator": Appropriate configuration provides: Assigning of static or dynamic (DHCP) IP address to a device;... -
Page 27: Wireless Computer Network (Wi-Fi)
Setting communication with server: IP or DNS address server 1 IP or DNS address server 2 (address of U-Prox IC A panel, optional) Access Ports (port to read and port to write) Period of the link channel checking (test signal) Wireless computer network (Wi-Fi) Panel can operate in wireless computer networks of standards IEEE 802.11b/g/n... - Page 28 Set up communication with the server: IP or DNS server address 1 IP or DNS address server 2 (address of U-Prox IC A panel, optional) Access Ports (port read and write port) Period of the link channel checking (test signal)
-
Page 29: Panel Programing
Panel programing Software Operation 1. Determination of panel operation mode: standalone or as part of ACS Software 2. Setting initial parameters: network settings of panel: "Configurator" Type of device - Wi-Fi or Ethernet connection Wi-Fi key of access to the network and encryption... -
Page 30: Maintenance
Maintenance Factory reset (before installation) To return panel to the factory settings, perform the following steps: De-power the panel Remove top cover of panel Short D1 (white) and D0 (green) wires Power up Wait for six beeps, signaling the successful panel reset...
