- Page 1 1.001 Access control panel U-Prox IP400 Installation and programming manual...
- Page 2 About this document his manual covers installation, adjustment and use of U-Prox IP400 (hereinafter panel) access control panel. Read this manual carefully prior to installing the system. Characteristics, Intended use and parameters of the panel are described in the section "Summary".
-
Page 3: Table Of Contents
Contents Brief description of the panel ....................4 Intended use ......................... 4 Characteristics ........................5 Terms ........................... 6 Description and operation ..................... 8 Panel ..........................8 Assignment of the access control panel ............... 10 Jumpers ........................11 Buttons ........................11 Sound and light panel .................... -
Page 4: Brief Description Of The Panel
Brief description of the panel U-Prox IP400 panel - a device designed to control access to residential and business premises, including time of passage of and events. Panel operates with two readers, which are connected to the access control panel via Wiegand interface. -
Page 5: Characteristics
Two relays (contacts NO, COM) 1 A @ 24 V One USB port for network settings configuring (for connection to ACS server) Ethernet port, 10BASE-T/100BASE-TX Adjusted with U-Prox IP software Real-time clock Antipassback Non-volatile memory:... -
Page 6: Terms
The information on the identifiers is read with READERS, connected to the ACS control panel. There are several types of RF IDs and readers for them. It is essential that reader and control panel use the same interface. U-Prox IP400 use Wiegand interface. - Page 7 This ensured that the system prevents situations when several users access the door with one RF ID or door left open after user’s access and so on. For these purposes the magnetic sensor of door closing, position sensor of the turnstile rotor and the position sensor of boom barrier are connected to the input of access control panel.
-
Page 8: Description And Operation
During downloading parameters are rewritten into access control panel. Description and operation Panel The look of the access control panel is shown in Fig. 1 The Enclosure The top cover of the Enclosure Tamper Fig. 1. U-Prox IP400 panel... - Page 9 Location of jumpers and removable pads with connectors on access control panel board and their function is shown in Fig. 2 Fig. 2. U-Prox IP400 components...
-
Page 10: Assignment Of The Access Control Panel
Assignment of the access control panel Contact Name Purpose Terminals for Loop normally closed normally elay contacts 1 disclosed С1 General normally closed Relay contacts 2 normally disclosed С2 General normally Relay contacts 3 disclosed С3 Total normally disclosed Relay contacts С4... -
Page 11: Jumpers
LED Data 1 Data 0 +12 V Power RS-485 A+ Port RS485, for future use RS-485 B- with extension modules RS-485 GND External power supply Battery OK Status of power supply Mains 220V OK Tamper Tamper switch USB connector... -
Page 12: Panel Operation
- waiting in uploading mode (jumper TMP off), this indication means that the attempt to upgrade the firmware failed 6 short blinks - successful upgrade of firmware 2 short blinks - uploading mode exit 6 short beeps (enclosure opened and shorted jumper FACT) - Factory... -
Page 13: Alarm" Mode
Cards (RF IDs) and schedules are not loaded in the panel (light off) access control panel is in unloaded state card is not enrolled in the panel card term expired (for 1 second buzzer is on and LED is red ) ... -
Page 14: Blocking" Mode
(A + B). As long as access point is in "Free Pass" mode, the lock is held in open position, the panel stores a log event "Access granted" on presentation of RF ID code regardless of the antipassback state of, schedules, etc. -
Page 15: Variants Of Use And Modes Of Output
Panel communicator operates in the notification mode. If there is event (passage, violation of input) event report message is send ACS server. U-Prox IP400 panel can be connected to a computer network via wired connection (Ethernet). This ensures work within local network (see Figure 3) or via the Internet (see Fig. - Page 16 Update of IP status of address (announcement and extension of reserved IP, if DHCP) Determine accessibility of ACS server and U-Prox IC A control panel (IP or DNS name) Periodic sending of test signals If there is, sending of events. Waiting for server commands.
- Page 17 Server addresses automatic configuration for control panel The use of the existing computer network infrastructure, standard network protocols (DHCP for instance) allowed to provide the “plug-and-play” principle. The mode of the automatic server address configuration in the panels eases the access system deployment significantly.
-
Page 18: Global Antipassback
U-Prox IP400 control panel can operate in a system of global antipassback. The main controller U-Prox IC A tracks the location of a person on the fact of its passage through the access point. U-Prox IC A receives data about the passages from control panels NDC F18 IP, U-Prox IP100, U-Prox IP300, U-Prox IP400. - Page 19 Fig. 7. Tracking the violations In case of lost communication with the access control panels, forced entry, free pass, etc. U-Prox IC A merges access areas together , considering that the personnel may be both there and there. After restoring the normal state of access point or communication with the control panels, areas will be unmerged (See Figure 8).
-
Page 20: How To Work With The Device
In configuring server address # 1 has to be the ACS server address. In configuring server address #2 has to be the address of the U-Prox IC A In the U-Prox IP software must be enabled antipassback mode "General"... -
Page 21: Connection Procedure
Connection procedure Before installation, do initial setup of panel (that specifies settings of network parameters) with utility "Configurator" via USB port When the panel is in stand-alone mode, paragraphs 11 and 12 should be performed before paragraph 2. In the place of installation of the panel do preparing - mark and drill the holes... -
Page 22: Connecting External Readers
Connecting external readers The panel has two Wiegand format ports for external readers. Together with access control panel a variety of readers can run. In Fig. 11 connection of readers is shown. Fig. 11. Connecting external readers Color matching circuits: ... -
Page 23: Connecting Loopcontrol
Connecting LoopControl Panel has eight inputs for connecting the loops supervised with end of line resistors. Each input functionality programmable. Inputs' functions are: Door Contact Door Contact + RTE Free pass (A, B, A+ B) ... -
Page 24: Door Contact
Z1 – Request to Exit button (RTE) of access direction A Z2 - RTE of access direction B The use of button of the electric lock to open access point or "allow access" button on the turnstile evokes the "DOOR FORCED OPEN" event For proper operation, it is necessary to assign the connected loops as RTE when programming. -
Page 25: Combined Loop- Rte And Door Contact
Combined Loop- RTE and Door Contact Panel inputs can be configured for simultaneous use of RTE button and Door Contact on single loop. In this case the loop breaking means breaking of Door Contact and (short-circuit) shorted - pressing of RTE button. -
Page 26: Actuators
Fig. 15. Connecting Blocking and Free Pass loops Z7 and Z8 inputs function assigned as follows: Z7 – Blocking A+B Z8 – Free Pass A+B "Blocking" can be assigned to the direction of passage A, B and A + B "Free Pass"... -
Page 27: Electric Locks
Electric locks Normally closed and normally open relay contacts, are programmable for a wide range (0 ... 255 sec) of lock operation time. Thus panel may control a wide range of electric locks and latches of almost any type. -
Page 28: Connection
Connection Wired computer network used for U-Prox IP400 communication to the ACS server. Device setup is possible with using autoconfiguration or manually with a PC using the software "Configurator": Appropriate configuration provides: Assigning of static or dynamic (DHCP) IP address to a device;... - Page 29 Setting communication with server: IP or DNS address server 1 IP or DNS address server 2 (address of U-Prox IC A panel, optional) Access Ports (port to read and port to write) Period of the link channel checking (test signal)
-
Page 30: Panel Programming
Panel programming Software Operation Determination of access control panel mode: standalone or as part of ACS The"Configurator" Setting initial parameters: network settings of Software- connect access control panel: via USB port Server settings: IP address or DNS name of... -
Page 31: Maintenance
Maintenance Factory reset To return access control panel to the factory settings, perform the following steps: Open enclosure Disconnect access control panel Set jumper FACT Power up Wait for six beeps, signaling the successful panel reset Disconnect panel Remove jumper FACT, close enclosure...
