Summary of Contents for CADDX NX-582
-
Page 1: Table Of Contents
GENERAL DESCRIPTION ..............2 ENCLOSURE INFORMATION ..............2 NX-582 ADDRESS ................3 ENROLLING ..................3 UNDERSTANDING THE LIGHTS ............3 WIRING THE NX-582 ................4 NX-582 LAYOUT.................. 4 TERMINAL DESCRIPTION ..............4 NX-582 WIRE REQUIREMENTS............5 PROGRAMMING THE NX-582............... 5 PROGRAMMING DATA................. -
Page 2: General Description
GENERAL DESCRIPTION The NX-582 is a microprocessor-controlled AES radio interface. This interface allows any or all events from the NX-8 control panel to be reported via the AES radio Model 7050-E and 7750-E. ENCLOSURE INFORMATION Inside the can, several 2-holed insertion points have been constructed. -
Page 3: Nx-582 Address
AService@ LED will illuminate. UNDERSTANDING THE LIGHTS The NX-582 has five (5) red LEDs along the front of the board. These LEDs provide valuable information about the status of the NX-582 and the AES radio... -
Page 4: Wiring The Nx-582
WIRING THE NX-582 Wire the 3-position terminal on the NX-582 to the NX-8 control panel keypad interface as follows: Positive to KP POS, COM to KP COM, and DATA to KP DATA. Connect the wiring harness from the NX-582 connector labeled J6 to the AES radio connector labeled J1. -
Page 5: Nx-582 Wire Requirements
Select the Module to Program All modules connected to the NX-8 are programmed through the keypad. Enter the address of the NX-582, which is [7]-[7], followed by [#]. The Armed LED will illuminate while it is waiting for a programming location to be entered. -
Page 6: Programming Data
will exit from this location, and the "Armed" LED will illuminate again waiting for a new programming location to be entered. If the desired location is the next sequential location, press the [POLICE] key. If the previous location is desired press the [FIRE] key. If the same location is desired press the [MEDIC] key. - Page 7 1. Numerical Data Numerical data is programmed by entering a number from 0-255 on the numeric keys of the system keypad. To view the data in a location, a binary process is used. With this process, the LED=s for zones 1 through 8 are utilized, and the numeric equivalents of their illuminated LED=s are added together to determine the data in a programming location.
-
Page 8: Programming The Locations
PROGRAMMING THE LOCATIONS Location 0 - Account Code (6 segments numerical data) This account number is provided by AES. Enter the account code followed by a “10" in the segment immediately after the last digit. If the account code is 6 digits long, program all 6 digits. -
Page 9: Programming Worksheets
PROGRAMMING WORKSHEETS DESCRIPTION Account Code (from provider) Default: AAAAAA Partition Event Enables 1 - Partition 1 5 – Partition 5 2 - Partition 2 6 – Partition 6 3 - Partition 3 7 – Partition 7 4 - Partition 4 8 –... - Page 10 Segment 6 1 - Open ‘ 5 - Autotest 2 - Close ‘ 6 - Program Start ‘ 3 - Exit Error ‘ 7 - Program End ‘ 4 - Recent Close ‘ 8 - Download Start Segment 7 1- Download Complete 4- Ground Fault Restore 2- Cancel 5- Maintenance Test...
- Page 11 Segment 6 1 - Open ‘ 5 - Autotest 2 - Close ‘ 6 - Program Start ‘ 3 - Exit Error ‘ 7 - Program End ‘ 4 - Recent Close ‘ 8 - Download Start Segment 7 1 - Download Complete 4 - Ground Fault Restore 2 - Cancel 5 - Maintenance Test...
-
Page 12: Specifications
DEFECTIVE PARTS AND WORKMANSHIP FOR TWENTY-FOUR (24) MONTHS FROM DATE OF MANUFACTURING. IF ANY DEFECT APPEARS DURING THE WARRANTY PERIOD, RETURN IT TO CADDX POSTAGE PREPAID. THE UNIT WILL BE REPAIRED AND RETURNED AT NO CHARGE. FOR THE REMAINING 36 MONTHS OF WARRANTY, THE CHARGE TO REPAIR OR REPLACE THIS MODULE WILL NOT EXCEED $10.00 PLUS...
