Product Description
F P
RONT ANEL
Figure 1 shows the front panel of the EDU-409 List 1, and
the doubler unit components.
Configuration
(located on side)
Table 3. Front Panel Components and Labels
Name Function
Status LED Indicates operational status of doubler. See
Configuration Contains either a five-digit or six-digit warranty configuration number or
number a standalone two or three-digit configuration number as follows:
The configuration number can also be found on a small bar label that also
contains the Julian date code and part number. This gummed label may
be attached to the PC board or to the front panel.
6
number label
Figure 1. EDU-409 List 1 Front Panel
Digit 1 = Last digit of shipment year
Digits 2 and 3 = Shipment month
Digits 4 and 5 = Configuration number
January 26, 2000
EDU-409
HiGain
DOUBLER
L
STATUS
150-409-115-05, Issue 5
Table 3 describes
Status LED
Table 4 on page 9.
EDU-409 List 1
