- Page 1 MASTER SERIES Econet Module Fitting Instructions...
- Page 2 Any modification or upgrade carried out to the printed circuit board of any ACORN equipment is undertaken at the sole risk of the person carrying o u t t h e m o d i f i c a t i o n o r u p g r a d e . N o c l a i m f o r...
- Page 3 half of the case by lifting it directly upwards from the machine. Included in the ECONET module upgrade kit are two plastic printed circuit board support posts. These must be fitted to the main printed circuit board before installing the ECONET module. The positions at which these posts are to be fitted are shown in figure 1.
- Page 4 Installing the ANFS H a v i n g f i t t e d t h e E C O N E T m o d u l e , i t i s n e c e s s a r y t o f i t t h e A d v a n c e d Network Filing System (ANFS) ROM.
- Page 5 Upgrading the Master Compact Unplug all peripherals and remove the power lead from the computer. Lay the computer face down on a flat surface and undo-the four case fixing screws. Gently turn the computer over allowing the screws to fall free. Put them in a safe place until required again.
- Page 6 aligned, ECONET module P.C.B pressed gently into place. The ECONET module is correctly seated when the barbs on the tips of the P.C.B supports have cleared the surface of the ECONET module P.C.B. An audible click should be heard when the barbs spring into place securing the P.C.B.
- Page 7 Acorn Computers Limited Fulbourn Road Cherry Hinton Cambridge CB1 4JN England Part Number 0459,200 Issue 1 September 1986...
