Instruction Manual
(With Warranty Card)
Small Sized Frequency
Variable Controller
Basic Type
K-ECF25 (Control capacity 2A)
K-ECH45 (Control capacity 4.5A)
This Instruction Manual is applicable to Version 02.0 onward. Please use
after confirming information displayed immediately after the power supply
is turned ON. (Refer to P.22)
Introduction
Thank you for your purchase of NTN small sized frequency variable controller (basic type). In order to
correctly and safely operate this controller, be sure to read through this instruction manual before using this
device. This instruction manual with guarantee certificate shall be delivered to end users without fail. In addition,
users shall keep this manual at the safe place where readily available whenever needed even after reading.
1.
Before usage
In order for you to use this device correctly and
safely and to make the most of its function, notes
below and on the next page shall be observed.
On receiving this device, please check if there is
any failure due to the transportation. If you find
any inconvenience such as a failure, do not
hesitate to contact the nearest sales office.
This controller is only for NTN electromagnetic
parts feeder. Usage in other than this application
or usage exceeding the specification range is
prohibited. It may cause failures.
The "parts feeder" described in this instruction
manual is the generic names for the bowl feeder,
the linear feeder and so on.
Read the Instruction
Manual to the last before use and
operate the machine correctly.
Ｖ．Ｆ． ＣＯＮＴＲＯＬＬＥＲ
ＡＣ１００－１１５／２００－２３０Ｖ ５０／６０Ｈｚ ２Ａ
Introduction
･････････････････････････
1. Before Usage
･･･････････････････････
4. Appearance & Names of Portions
5. Installation
･･････････････････････････
7. Connection of Input/Output
（F – V Curve）
･･･････････････････････
11. Troubleshooting
12. Specification (Outside Dimensions)
1
PMPC034E-d
№
Ｋ－ＥＣＦ２５
Ｋ－ＥＣＨ４５
ＲｏＨＳ
ＲｏＨＳ
ＲＵＮ
ＲＵＮ
ＦＵＮＣ
ＲＵＮ
ＦＵＮＣ
ＲＵＮ
ＲＥＳＥＴ
ＪＯＧ
ＲＥＳＥＴ
ＪＯＧ
ＤＡＴＡ
ＤＡＴＡ
ＳＴＯＰ
ＳＴＯＰ
ＥＮＴＥＲ
ＥＮＴＥＲ
ＪＡＰＡＮ
Ｖ．Ｆ．ＣＯＮＴＲＯＬＬＥＲ
ＪＡＰＡＮ
ＡＣ１００－１１５／２００－２３０Ｖ ５０／６０Ｈｚ ４.５Ａ
l
l
0
0
ECF25
ECH45
Contents
･･･････････････････
･････････････････
･････････
････････････････････
･･････････
･･･････････
21 to 26
･･････････････
26 to 37
39 to 40
････････
･････････････････
41 to 42
･･･
43 to 44
･･･････････
Page
1
1
2 to 4
5
6
7
8
9 to 20
38
45
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for NTN K-ECF25
Summary of Contents for NTN K-ECF25
- Page 1 ECH45 Introduction Thank you for your purchase of NTN small sized frequency variable controller (basic type). In order to correctly and safely operate this controller, be sure to read through this instruction manual before using this device. This instruction manual with guarantee certificate shall be delivered to end users without fail. In addition, users shall keep this manual at the safe place where readily available whenever needed even after reading.
- Page 2 It gets an electric shock, short-circuited, and is likely to ignite. This controller is a controller only for the NTN parts feeder (electromagnetic type vibration part supply machine). It is not possible to use it for other usages such as a piezo-electric type parts feeders and the single phase motors.
- Page 3 Warning It must not be used in a place where it exposes to water, oil or chemicals, or outdoors, or in a place of high temperature and humidity. There is a fear of an electric shock, a fire or a failure. Please do not scratch, pull or forcibly bend the wiring.
- Page 4 Caution Please do not install it in the place where the vibration or the impact is acting. The controller breaks down. Please refer to the note of caution on the margin below when doing the dielectric breakdown test and megger test (measurement of the insulation resistance by the meggohmmeter). The controller breaks down when making a mistake.
- Page 5 3. The one only written as LED indicates the data display portion on the operation side (Refer to P.6). 4. Original NTN terms such as “air blow during driving” is used. Please inquire of NTN for details of the operation.
- Page 6 4. Appearance and Names of Portions The following diagram is explained about K-ECF25. But the layout of parts is same with K-ECH45. (1) Appearance diagram （Please refer to P.44 for dimensions） Production No. (Ser.№) Fixing leg Operation panel Pilot lamp Data display Ｋ－ＥＣＦ２５...
- Page 7 ＲＥＳＥＴ ＪＯＧ ＤＡＴＡ ＳＴＯＰ ＥＮＴＥＲ Ｖ．Ｆ． ＣＯＮＴＲＯＬＬＥＲ ＪＡＰＡＮ ＡＣ１００－１１５／２００－２３０Ｖ ５０／６０Ｈｚ ２Ａ 2-R2.5 To mount the controller on the bowl feeder base, 30(60) purchase the separate optional unit. Base mounting bracket: K-PZ0466 Figures in ( ) are dimensions for ECH45 For details, ask NTN.
- Page 8 For the first time use When you use the controller first time after the purchase, please make connections of input-output, and set all kinds of functions according to the followings. In case that you purchase it as a completed product, setting etc. is not necessary.
- Page 9 Danger Connection of Input / Output Do the wiring work after cutting off the External connection diagram （Also refer to the block main breaker without fail. It is likely to diagram in the next page） get an electric shock. (Details of each wiring are described in the page shown in the notes written below, therefore please refer to them.) Caution Please select an appropriate type to the...
- Page 10 Controller block diagram（Refer to the previous page and the final page for wiring） Controller K-ECF25 (ECH45) コントローラ Ｋ－ＥＣＦ２５（ＥＣＨ４５） (Sequence order is different from the actual terminal array.) （実際の端子配列とは順番が違います） Power FUSE 電源 3A(ECF25) switch ｽｲｯﾁ （ 5A(ECH45) 突 +24V ば サ 入...
- Page 11 AC100V power supply. When you want to make it to the AC200V output by the AC100V input, change to the controller equipped with AC100V power supply unit is required. Please contact NTN for the details. Name of Color of lead...
- Page 12 (3) Connection of load line Please connect the load line (load cable of the parts feeder attachment) to the terminal board through 負 荷 White ２ controller's cable ground. As the voltage of max 接 １ 続 AC200V applies to this terminal, be careful of the wiring Ｎ...
- Page 13 Caution (4) Wiring of external control input 24V, X1 and 0V terminals have polarity. Please be careful of wiring enough. In addition, please never connect it to AC power. Jumper wire Remove jumper Caution wire Parts feeder's ON/OFF control must use the Magnified view external control input terminal.
- Page 14 Wiring method when controlling with PNP transistor output For the electric wire size for wiring, refer to the boxed article in the middle of the previous page. When controlling by the PNP transistor, please ２４Ｖ connect the output (collector) side of the PNP ＋Ｖ...
- Page 15 Caution (5) Connection of sensor/solenoid valve Driving stops when the power supply (DC24V) for the Basic method to use sensor and solenoid valve sensor is short-circuited (the display also is turned off). is explained as below. Please be careful of the wiring work sufficiently. 1．Overflow control by sensor Connection of 3 wire type sensor ①The work confirmation sensor that detects the overflow on the...
- Page 16 2. Air blow control during driving For the electric wire size for wiring, refer to the boxed article in the middle of P.13. When connecting the solenoid valve for DC24V to between 24V-P0, the solenoid valve can be turned on during driving the ２４Ｖ...
- Page 17 (4) The overflow sensor controls the normal overflow and also outputs the jam signal to the terminal P2 when the work is not detected for a certain time. It can be used for jam air blow control of NTN spring separate feeder.
- Page 18 (6) Multi-speed function (6) - 1. In case that memorized speed data is used Control signal must be either NPN transistor output type or no-voltage contact output type. ＩＮ１ It is possible to drive at the speed data (frequency and voltage 3.3k ＩＮ２...
- Page 19 (7) Wiring of drive instruction output The contact signal that is linked with parts Internal circuit feeder's driving comes out between terminals of Relay contact リレー接点 Y1C-Y1A. It is "Close" for driving and "Open" for Ｙ１Ａ Pilot signal 運転中信号 Ｙ１Ｃ the stop.
- Page 20 (9) Close the panel Please check whether there is a mistake in the connection of wiring. Content to be checked A) Isn’t there any mistake in the connection destination? Cable B) Isn’t there any mistake in the polarity? C) Isn't there possibility of short-circuit and earth fault? D) Is the earth surely connected? Was the protection ①Plug connector...
- Page 21 Driving and adjustment Caution Description of the operation panel Only when 2 or 3 (both are on the operation panel) is selected by the function J02, the RUN/STOP key can be used. Ｋ－ＥＣＦ２５ ＲｏＨＳ ＲＵＮ Name of each № Description portion LED of 7 seg 4 digits.
- Page 22 (1) Specification check and preparation of driving Caution Please check again whether neither the form, the specification Confirm certainly the setting of the nor the power-supply voltage of the controller are wrong before function before driving. When the turning on power. setting is mistaken, the magnet may burn.
- Page 23 (4) Driving Display during stop ①Please set the external control terminal to the driving side (short-circuit when function J02 is 1). Moreover, please press the RUN key when you have set the driving control method to the panel control (2 or 3) with the function J02.
- Page 24 ＤＡＴＡ ＥＮＴＥＲ ④Please press the data key twice and return to the voltage display when the adjustment ends. Fast-forward operation of frequency When you want to change the frequency to a large degree, usage of the fast-forward operation makes the frequency change in a short time possible.
- Page 25 (6) Speed (voltage) adjustment ①Please turn the speed adjustment knob gradually clockwise, and set it to the position at which a necessary amplitude is obtained. When an instruction of a proper position exists, please follow Set mark the instruction. Usually it is used between scales 4-7 (6-7 for full wave system and 4-5 for half wave system).
- Page 26 (10) Power supply OFF ①Please turn off the power after confirming that the driving has stopped. When LED is turned off, "LV" is displayed once. This is not abnormal though. Moreover, it is likely to take more than five seconds for LED to go out. ②The electric charge remains in the internal circuit although LED goes out.
- Page 27 ⑤Data is changed with UP/DOWN key. Note: The data of J00, J01, J04, J10, J11 (only ECH45), J12 and H11 in the function can be changed only when the driving is stopping. When you want to confirm data only, press the data key again or press the function key.
- Page 28 (2) List of functions There are two kinds of functions, J group that mainly sets functions and H group that mainly sets the data. Please refer to “Contents of functions” of P. 30~ for the detail of each function. Underlined figures are initial values for ECF25/ECH45. But own initial value only for ECH45 exists partly. The initial values are shown with broken line.
- Page 29 ＜ List of H group functions ＞ Change Record Change Record Name & Set range Name & Set range during of set Ｈ№ during of set Ｈ№ （Initial value is underlined） （Initial value is underlined） driving value driving value Soft start time Selection of functions of IN1 input 0.0~5.0(Sec.) Initial value 0.5 0:Driving with High input...
- Page 30 (3) Contents of the function (details) J Group (Related to function setting) Display Name Content Operation lock To prevent the operational error, operations by other than a specified key Initial value: 0 can be made unacceptable. The data of J00 can be changed only by Unchangeable during driving pressing the stop key and UP or Down keys at the same time for the operational error prevention.
- Page 31 Display Name Content Selection of driving method The input condition of the driving ON/OFF signal is switched. Initial value: 1 External control terminal: X1 terminal Overflow detection sensor input: IN1 or IN2 terminal 0: Driving by AND with the external control terminal signal and the overflow detection sensor (Both conditions must be on the driving sides).
- Page 32 When data is set to 1, it rewrites all data and frequency of the function (All clear) into the initial values at shipping from NTN. It is used when resetting from Initial value: 0 the beginning or clearing data content for return from error. All the values...
- Page 33 OFF. When either IN1 or IN2 is ON (the input of one or both turned OFF), the OFF delay timer works, makes P0 ON (Low) at the same time with the drive starting, and turns ON the corresponding P1 and P2. Please inquire of NTN for the detailed operation.
- Page 34 Display Name Description Selection of IN2 input function In case H03 is 0 or1, terminal IN2 is effective when H00 is 4 or 7, or when H08 is 2. Selection of IN1 input function In case H03 is 2 or 3, it is effective when H00 is 0~3. Initial value: 0 In case H03 is 4, it is effective when H00 is 0~1.
- Page 35 Display Name Description Work shortage timer Set the time of the timer that detects the work shortage. When the signal continues Initial value: 10.0 (second) for a set duration, the work shortage signal is set. The logic with which the timer works depends on H00 or H03, and the timer works when the input selected with Set range: H08 during driving (output ON) is Low (the reverse-operation is also possible by...
- Page 36 Panel lock In order not to have the set value changed even if an operator touches the knob by mistake, it is recommended to turn on the panel lock during the automatic operation. There are two kinds of panel locks, an operation lock set by the function and a simple knob lock.
- Page 37 Display at multi-speed driving Speed No. display When the multi-speedy driving is selected, the selected speed mark P1 etc. is displayed preferentially. When you want to confirm the set voltage and the frequency of driving, please press the data key. The display changes in order of speed № display => voltage display=>...
- Page 38 *3 When the parts feeder made by other company is used or a curve other than for F/H/C is selected, there is the case that protection by the F / V curve is impossible. Please note that NTN is not responsible for the trouble that originates from these circumstances.
- Page 39 Protection/Warning function (1) Protection function The protection function is an important function to protect a controller or peripheral equipments. When the protection function operates, it is short-circuited between terminals C2-EM. The reset work is necessary when stopping due to the protection function. Please reset it after investigating the cause that made the protection function to operate and executing the countermeasure (Refer to the next page for reset).
- Page 40 Additionally, we recommend that the external control signal is made "Stop" because there is a possibility that the parts feeder begins moving at the same time with the return when all cleared. *Please contact NTN when it is not possible to reset it.
- Page 41 Please investigate the following points if a trouble occurs by any chance. In addition, check the output voltage (Refer to P.42) for the case of paragraphs of (2) and (3). When the cause is not clear and it needs to consult NTN on the troubling state, please inform of the content in detail and concretely with referring the followings in order to be able to take measures as soon as possible.
- Page 42 Contents of troubles Estimated causes Reference pages/documents/measures (7) Reset is not effective. Press the reset key after the controller is ・ There is a signal of the driving stopped (Refer to P.40). instruction. (8) The output voltage The setting of the F-V curve is confirmed ・...
- Page 43 Specification Part number K-ECF25 K-ECH45 AC100V to 115V/AC200V to 230V±10% 50/60Hz（Automatic switching） Power supply Inrush current 50A or less（For initial 1 cycle） Control method Sine wave PWM control 2.0A （For continuous driving. Rating for short time 4.5A （For continuous driving. Rating for short time...
- Page 44 [Outside dimension diagram] K-ECF25 K-ECH45 K-ECF25 RoHS Ｋ－ＥＣＨ４５ ＲｏＨＳ ＲＵＮ FUNC RESET ＦＵＮＣ ＲＵＮ ＲＥＳＥＴ ＪＯＧ DATA STOP ENTER ＤＡＴＡ ＳＴＯＰ ＥＮＴＥＲ V.F. CONTROLLER JAPAN AC100-115/200-230V 50/60Hz 2A Ｖ．Ｆ．ＣＯＮＴＲＯＬＬＥＲ ＪＡＰＡＮ ＡＣ１００－１１５／２００－２３０Ｖ ５０／６０Ｈｚ ４.５Ａ SPEED 12.5 ※ The cable grand etc. are omitted on the front view so that the mounting holes are visible.
- Page 45 ・This manual might be changed without notice for the function improvement etc. Revised : July 1, 2013 Issued : Aug. 18, 2010 Technical Service Corporation Product engineering section Precision equipment dept Iwata Division 1578 Higashi-Kaizuka, Iwata, Shizuoka 438-8510 Japan PHONE：81-0538-37-8104 FAX：81-0538-37-8128 All rights reserved. ©NTN Technical Service Corporation 2013...
