Louvolite R1730 Operating Instructions

Up Button
Stop Button
Down Button
Channel <
STEP 1 - PAIRING THE HANDSET WITH THE MOTOR
NOTE: During the setting procedure, the time between two operations must
not exceed 4 seconds as this will cause the setting up process to quit.
2 jogs = 1 movement, up AND down
• Switch on the power to the motor
• Remove the battery cover on the reverse of the remote. There are two setting buttons (P2) on either side of the battery,
press either one
• Select a channel from 1- 15 on the remote by pressing channel up or down (< or >)
• Press the button on the motor and the motor will jog up and down
• Press P2 twice then the up or down button once. The motor will jog twice each time
The motor and remote are now paired.
• R1740 - To change direction press and hold the button on the motor for 2 jogs
• R1725 - To change direction press and hold the button on the motor for 4 jogs
STEP 2 - SETTING THE LIMITS
Select the same channel and set the top limit.
• Press P2, then the up button followed by P2 again, the motor will jog twice and beep
• Press the up button and the blind will start to rise
• Press P2 and the blind will go into slow jog mode
• Press the stop button on the remote and the blind will stop
• Hold the stop button down until the motor jogs twice, this will set the top limit
• Press the down button and the blind will start to go down
R 1 7 3 0 R E M O T E C O N T R O L
fo r us e w ith R1725 & R17 40 mo to rs
operating in s tr uc t i ons
LCD
Screen
Channel >
Setting Button
