GROLAB USERBOT HW01 Installation Manual page 3

1
RF communication antenna
2
RF antenna outlet
3
RF module
4
RF interrupt pin
5
Universal breakout board
6
Female pin headers
7
Arduino connec on pins
8
4 x TO-92
9
2 x SOT26
10
3 x SSOT223
11
2 x TSSOP-8 (=) 1 x TSSOP-16
12
SOIC16
EN
ES
FR
PT
IT
2
