Future Design VR18 Procedure Of Replacing

Hide thumbs Also See for VR18:

Procedure of Replacing VR18 Input Power Module

Power Module Installation Procedure is the same for all modules.

Power Module Part Numbers are:

PM181: 90-264 VAC

PM182: 9-18 VDC

1. Turn off the power, disconnect all power & communication cords and remove I/O cards located in

the rear slots.

2. If it is panel-mount style, remove the mounting clamp. If it is bench top/portable style, remove the

handle, two ears and two feet as described below; figure references may be found in the VR18

Manual.

a. The handle: Remove it in a reverse way as Figure 2-11, 2-10 & 2-9.

b. Two ears: Remove them by pulling toward the backside.

c. Two feet: Remove them in a reverse way as Figure 2-14, 2-13 & 2-12.

3. Remove six screws in the back, then take off the metal housing

VR18-Install Input Power Module.doc

PM184: 90-264 VAC w/plug receptacle;

PM183: 18-36VDC

[provided with Bench Top Option]

PM185: 32-72 VDC

P.O. Box 1196 / Bridgeview, IL 60455

888.751.5444 / 888.307.8014 fax

Technical Support: 866.342.5332

http://www.futuredesigncontrls.com

Table of Contents

Do you have a question about the VR18 and is the answer not in the manual?

Page 1 2. If it is panel-mount style, remove the mounting clamp. If it is bench top/portable style, remove the handle, two ears and two feet as described below; figure references may be found in the VR18 Manual. a. The handle: Remove it in a reverse way as Figure 2-11, 2-10 & 2-9.
Page 2 PM181 90-264VAC Power Input Module PM184 90-264VAC Power Input Module w/plug receptacle; replaces power input terminal block [Provided with Bench Top Option] VR18-Install Input Power Module.doc P.O. Box 1196 / Bridgeview, IL 60455 888.751.5444 / 888.307.8014 fax Technical Support: 866.342.5332...
Page 3 8. Turn the main part upside down. Put on the metal housing and then fix it by six screws. 9. If it is panel-mount style, put the mounting clamp back. If it is bench top/portable style, put the handle, two ears and two feet as described below; figure references may be found in the VR18 Manual.
