Specifications

Technical:
HDMI Input (Each): HDMI Connector, Type A, 19 Pin Female
›
HDMI Output: HDMI Connector, Type A, 19 Pin Female
›
HDMI Bandwidth: TMDS bandwidth 18Gbps
›
DDC Signal (Data): Input DDC Signal - 5 Volts p-p (TTL)
›
HDMI Video/Audio Signal: Input Video Signal - 1.2 Volts p-p
›
3.5mm Stereo Audio Output: Line level audio on TRS connector. Drives 1 VRMS line
›
audio output with a sampling rate of 48kHz
Analog Audio Max Output Level: 4dBu on 150kΩ, DC coupling
›
Digital PCM Audio Output: RCA female for digital audio following SPDIF format (IEC
›
60958). Supports sampling rate up to 192KHz
PCM Max Output Level: 1Vpp on 75Ω, DC coupling
›
Audio Bandwidth: 20Hz to 20kHz @ 0dBu
›
TND + Noise: 0.33% @0dBu @ 1kHz
›
PCM Max Input Level: 1Vpp on 75Ω, AC coupling
›
Power Supply: KD-PS5V1ASC, 5V/1A, 100-240VAC, 50-60Hz, Interchangeable head,
›
screw-in connector
General
Regulation: CE, RoHS, WEEE, EAC
›
Enclosure: Black metal
›
Power Supply: USB to micro USB cable (power adapter not included)
›
Product: 2.17" x 3.085" x 0.68", Weight: 4 oz
›
Packaging: 2.5" x 3.5" x 1", Weight: 6 oz
›
Important Product Warnings:
Connect all cables before providing power to the unit.
1.
Test for proper operation before securing unit behind walls or in hard to access
2.
spaces.
If installing the unit into wall or mounting bracket into sheet-rock, provide proper
3.
screw support with bolts or sheet-rock anchors.
Safety Instructions:
Please be sure to follow these instructions for safe operation of your unit.
Read and follow all instructions.
1.
2. Heed all warnings.
Do not use this device near water.
3.
Clean only with dry cloth.
4.
5. Install in accordance with the manufacturer's instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or other
6.
apparatus (including amplifiers) that produce heat.
Only use attachments/accessories specified by the manufacturer.
7.
8. Refer all servicing to qualified service personnel. Servicing is required when the device
has been damaged in any way including:
Damage to the power supply or power plug
»
Exposure to rain or moisture
»
Power Supply Use:
You MUST use the Power Supply PROVIDED with your unit or you VOID the Key Digital
Warranty and risk damage to your unit and associated equipment.
