KD-VW4x4Pro
4 Inputs to 4 Outputs
Video Wall Processor,
supports Seamless Matrix Switching
Operating Instructions
The Experts in Digital Video Technology and Solutions
™
Advertisement
Table of Contents
Related Manuals for Key Digital KDVW4X4PRO4K
Summary of Contents for Key Digital KDVW4X4PRO4K
- Page 1 , led by digital video pioneer Mike Tsinberg, ® develops and manufactures high quality, cutting-edge technology solutions for virtually all applications where high-end video and control are important. Key Digital ® is at the forefront of the video industry for Home Theater Retailers, Custom Installers, System Integrators, Broadcasters, Manufacturers, and Consumers.
-
Page 2: Table Of Contents
How to Contact Key Digital ........ -
Page 3: Quick Setup Guide
Application Example Rack Mounting: Secure the rack ears to each side of the KD-VW4x4Pro with the supplied hardware, then fasten › VGA Laptop HDMI Laptop the unit to the rack rails with the included machine screws. Digital Signage Cable/Satellite Quick Setup Guide 1. -
Page 4: Connections, Buttons And Leds
Connections, Buttons and LEDs Output Connections Located on the right side of the back panel. Rear Panel Connections: HDMI Outputs (4 Total) › All connections to the KD-VW4x4Pro are found on the rear panel of the unit. Refer to the Compatible with HDMI 1.3b standard »... - Page 5 Front Panel Operation Video Wall Mode Select: (2 rows of four buttons) › Enables the selected source to be displayed across all outputs in the desired layout » Matrix Mode Switching To select video wall mode: » 1. Choose the desired video wall layout »...
-
Page 6: Ir Remote Control
IR Remote Control 3 Vertical x 1 Horizontal The IR Remote Control included with KD-VW4x4Pro provides convenient, but limited control of the switching features and 1 Vertical x 2 Horizontal, Mirrored unit setup. In addition to discrete power on, power off buttons and function buttons R1, R2, and R3, there are 3 main groups of 2 Vertical x 1 Horizontal, Mirrored controls:... -
Page 7: Video Wall Modes
Addressing via IR Important Note about Source Content: The KD-VW4x4Pro may be addressed to avoid controlling multiple units with one IR remote. Once It is necessary to obtain/create content that maintains the aspect ratio of the video wall mode. applied, all IR remote controls must precede with a two digit number before sending the IR remote A common display’s aspect ratio is 16:9. - Page 8 Video Wall Mode 2 Configuration Video Wall Mode 3 Configuration 1 vertical x 4 horizontal with displays rotated 90 4 Vertical x 1 Horizontal degrees counter clock-wise Ideal aspect ratio of source content, 16:36 › Ideal aspect ratio of source content, 36:16 ›...
- Page 9 Video Wall Mode 4 Configuration Video Wall Mode 6 Configuration 1 Vertical x 4 Horizontal 1 Vertical x 2 Horizontal, Mirrored Ideal aspect ratio of source content, 64:9 Ideal aspect ratio of source content, 16:27 › › Original Source: Original Source: 1V x 4H Video Wall Output: 3V x 1H Video Wall Output: Video Wall Mode 5...
- Page 10 Video Wall Mode 7 Configuration Video Wall Mode 8 Configuration 1 Vertical x 2 Horizontal, Mirrored 2 Vertical x 1 Horizontal, Mirrored Ideal aspect ratio of source content, 32:9 Ideal aspect ratio of source content, 16:18 › › Original Source: Original Source: 2V x 1H Video Wall Output: 1V x 2H Video Wall Output:...
-
Page 11: Rs-232 & Tcp/Ip Commands
RS-232 & TCP/IP Commands The KD-VW4x4Pro provides access to all functions when used with an RS-232 or TC/IP control system or computer. The connection protocol is as follows: RS-232 cable pin out Baud rate: 57,600 » Data Bits: 8 » Parity: None »... -
Page 12: Bezel Control For Video Wall Mode
Bezel Control for Video Wall Mode Window Border The area on the outer edge of each display may be pinched to make the images blend together through the display’s bezel. These commands may be used to adjust these bezels. For Left Border: SPO xx VCL yy »... -
Page 13: Specifications
Specifications There are 4 kinds of borders for each display: Technical: Input (Each): 1 HDMI connector, Type A, 19 pin female; 1 HD analog video 15-pin female, › 1 analog audio connector, 3.5mm stereo female Output (Each): 1 HDMI connector, Type A, 19 pin female ›... -
Page 14: How To Contact Key Digital
Warranty and risk damage to your unit and associated equipment. All Key Digital ® products are built to high manufacturing standards and should provide years of trouble-free operation. They are backed by a Key Digital Limited 3 Year Product Warranty Policy. http://www.keydigital.com/warranty.htm...
