- Page 1 OWNER’S MANUAL TRINITY ECOSTORAGE® 6-TIER NSF WIRE SHELVING RACK W/ WHEELS – CHROME MODEL # TBFZ-0945...
-
Page 2: Parts List
Your TRINITY EcoStorage® 6-Tier NSF Wire Shelving Rack w/ Wheels should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. Parts can also be requested online at www.trinityii.com (Help &... - Page 3 (8) SLIP SLEEVES (D) on BOTTOM POLES (B) are at the same level. Note: For stability, the lowest SLIP SLEEVES (D) should be installed no higher than the 3rd indentation from the caster end of BOTTOM POLES (B). © 2017 TRINITY - 800.985.5506...
- Page 4 POLES (B) and assemble one more SHELF (C). Note: • The level side of SHELF (C) is the TOP side (the TRINITY logo on the corner cylinders should be right-side up.) • Use a rubber mallet, if needed, to secure SHELF (C).
- Page 5 Push in (4) END CAPS (J) into the tops of BOTTOM POLES (B). Place (8) SLIP SLEEVES (D) on the last indentation of (4) BOTTOM POLES (B) and place SHELF (C) corner cylinders onto SLIP SLEEVES (D) to complete one 3-Tier Rack with Casters. © 2017 TRINITY - 800.985.5506...
- Page 6 INSERTS (I). Screw (4) FEET LEVELERS (H) into THREADED INSERTS (I). STEP 6 D (24) C (3) Following STEPS 1 – 3, assemble (3) SHELVES (C) onto TOP POLES (A) to complete another 3-Tier Rack with Feet Levelers. © 2017 TRINITY - 800.985.5506...
- Page 7 SERVICE PARTS LIST – TBFZ-0945 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XBK-23-004-2517 End Cap XBK-01-011-2543 Slip Sleeve ZSV-04-006-3600 Top Pole XXX-97-002-0001 Wrench ZSV-01-013-2523 Pole Connector ZSV-99-007-4010 Non-locking Caster ZSV-04-042-3600 Bottom Pole ZSV-01-014-2513...
-
Page 8: Care And Maintenance
2727.3 kg / 6000 lb (on Feet Levelers) 363.6 kg / 800 lb / (on Casters) (evenly distributed) CARE AND MAINTENANCE • Avoid harsh, abrasive cleaners, and other corrosive chemicals. • This item is not certified for outdoor use. © 2017 TRINITY - 800.985.5506... -
Page 9: Product Registration
PRODUCT REGISTRATION Thank you for purchasing a TRINITY EcoStorage® 6-Tier NSF Wire Shelving Rack w/ Wheels. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com. - Page 10 © 2017 TRINITY - 800.985.5506...
-
Page 11: Year Limited Warranty
TRINITY EcoStorage® 6-Tier NSF Wire Shelving Rack w/ Wheels (“Product”) that each Product shall be free from defects in workmanship and materials for a period of 1 year from the date of original purchase. Trinity’s obligation under this warranty shall be limited to repair or replacement of, or adequate compensation for the Product which shall not be greater than the amount of the purchase price of the Product, at the option of Trinity, during the warranty period. - Page 12 WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com Monday through Friday 8:00 AM –...
