Technical Specifications; List Of Illustrations; List Of Tables - Johnson Controls VCC-64 User Manual

User Manual: VCC-64
• Do not use aerosol sprays, solvents or abrasives.
• Do not spray any cleaning products directly on the device.
Operation:
• Wipe the system with a damp cloth.
5

TECHNICAL SPECIFICATIONS

Model
Power supply
Consumption
Bus RS-485
Address
Volume Buttons
Volume Steps
Source Buttons
Channel Range
Functioning Conditions
Finishing
Weight
Drill Installation (HXWXD)
Dimensions (HxWxD)
6

LIST OF ILLUSTRATIONS

Figure 1 - Connections ............................................................................................................... 6
Figure 2 - Cabling ...................................................................................................................... 8
7

LIST OF TABLES

Table 1 - Active Mode ................................................................................................................ 5
Table 2 - Active Mode Display .................................................................................................... 5
Table 3 - Connections ................................................................................................................ 7
Table 4 - Bus Addresses ............................................................................................................ 7
Table 5 - Technical Specification ............................................................................................... 9
9
VCC-64
12V DC
1.2W max (100mA)
Max. distance 1000m/ 3280,8 ft. (Max. 8 VCC-64 connected by
bus)
Dip-switch 3 bit
VOL- / VOL+
0-9
CH+ / CH-
64 / 01 BGM + MIC LOCAL
-5ºC to +45 ºC /23 ºF to 113 ªF
5% to 95% Relative Humidity (without condensation)
ABS RAL 9016
110gr 3,88 oz
62mm x 70mmx 35mm / 2,44" x 2,75 x 1,38
86mm x 86mm x45mm / 3,38 x 3,38 x 1,77
Table 5 - Technical Specification
Rev.0.3
