- Page 1 Owner´s Manual IP Cameras & Domes GBR-CM02 Corner Mount Adapter GBR-CM02.20.1.02.08.2011 © ASP AG...
- Page 3 Content: 1. Introduction 2. Package Contents & Needed Items 3. Installation 1. Introduction The Dome Cameras GCI-H0522V and GCI-K0322V can be mounted in an upper corner with this Corner Mount Adapter. The items and tools needed for installation are listed below. 2.
- Page 4 3. Installation Step 1: Match the Corner Mount Adapter to the ceiling corner. Please note that the Dome Camera’s Housing installing holes are in position as shown in the figure on the left. Step 2: Drill six holes on the walls and the ceiling to install six M4 plastic anchors.
- Page 5 Step 5: Thread the RJ-45 cable (and a power cable if needed) through the Dome Camera’s Housing. Step 6: Tighten the four M4 Screws to install the Dome Camera’s Housing in the Corner Mount. Step 7: Place the Camera Module into the Dome Camera’s Housing until there is a “click”...
- Page 6 Step 9: Connect the RJ-45 cable (and the power cable if applicable) to the Camera Module, and then adjust the Dome Camera lens to a desired angle. Please note that the zoom level and focal length might be different with the Dome Cover on, in this case, adjusting zoom level and focal length through the Dome Cover is recommended.
- Page 7 Specifications GBR-CM02 Suitable for GCI-H0522V; GCI-K0322V Body material Steel Colour White Weight 0.5 kg Dimensions (wxhxd) 222 × 204 × 117 mm English...
