- Page 2 - 2 - #OMEGA-3v9k INSTALLING THE ESC. We usually supply the # OMEGA-3v9k ESC with a Lemon brand Rx which is simply plugged in upside down on the ESC pcb in the 24 pin socket. The two parts are bench tested to make sure they work correctly.
- Page 3 2. Rewire the lights so that the loco will have constant brightness auto reversing head and tail lights. This can get complicated and is not advised unless the installer has some experience. See below. N.B DO NOT WIRE ACCUCRAFT 1.5 VOLT BULBS DIRECT TO THE OMEGA-3v9k LIGHTING OUTPUTS. POWER SOURCES.
- Page 4 - 4 - #OMEGA-3v9k SETTING UP THE ESC. TX-3, TX-5 & TX-7 THESE INSTRUCTIONS REFER TO THE 2.4 GHz 5 CHANNEL R/C. ALL THE ABOVE TX’s USE THE SAME BINDING PROCEDURE. Prior to using this system there are two procedures that must be carried out by the operator, unless the TX and RX have already been bound and the system calibrated;...
- Page 5 - 5 – 2. CALIBRATION. All RCS # OMEGA-3v9k systems are pre-calibrated when sent out, using one of our own TX handpieces. Please test the system before re-calibrating it. Assuming the RX has been correctly plugged into the ESC the system will perform as described later.
- Page 6 - 6 - 3. PROGRAMMING. he # OMEGA-3v9k Operating features of t system can be adjusted from the TX using the ESC pushbutton. Programming can only take place when the system is in neutral. 3.1 START VOLTAGE. This feature is designed to equalise the starting voltage of dissimilar locos.
- Page 7 2. Sound powered by ESC. Already has a common ground. The # OMEGA-3v9k ESC has 4 x sound triggers. Two controlled by the two small push buttons on the TX-3, and four controlled by 4 x small pushbuttons on the TX-5 & TX-7 handpieces. The Tx-5 can use the AUX-1 and AUX-2 servo knobs.
-
Page 8: Troubleshooting
- 8 - #OMEGA-3v9k ESC MU’ing LOCO CONSISTS. MULTIPLE LOCOS IN A CONSIST. The # OMEGA-3v9k ESC is capable of MU’ing multiple locos into one consist of locos. If you intend to do this often we strongly recommend you use the # DSM2-EM(AB) in all locos. These bind automatically which is much simpler than using a binding plug.
